Migration from MC35 to MC35i
PRELIMINARY
Migration from MC35 to MC35i
7 of 30 12.03.03
3 Feature migration
Feature comparison for both modules introduced in the table below. Only main specifications
are listed.
3.1 General description
Table 1: General description a)
Features Parameter MC35 MC35i
Frequency bands:
Dual-band EGSM 900, GSM1800
compliant to GSM Phase 2/2+
Output performance: Class 4 (2W) for EGSM900
Class 1 (1W) for GSM1800
Receiver Sensitivity: < -102 dBm
GSM Class: small MS
Control: via AT commands
3 V Supported SIM card:
External SIM card holder has to be connected via SIM interface connector
Phonebook management: SM, FD, LD, MC, RC, ON, ME
3.3 – 4.8 V 3.3 – 4.8 V Input voltage range:
Automatic shutdown supported
Component mounting: both sides single-side mounted
Dimensions: 54.5 x 36 x 6.65 mm 54,50 x 36 x 3,6
Weight: 16 g 9 g
-25°C to +55°C (normal operation) -20°C to +55°C (normal operation)
+55C to +70°C (restricted operation)
-29°C to -25°C (restricted
operation)
-25°C to -20°C (restricted operation)
-40°C to +85C (storage)
Temperature conditions
Automatic shutdown supported (>+70°C and <-29°C)
Battery Charging: Supported Not supported
Real time clock: Implemented
Timer function: Programmable via AT command
Antenna design: 50W antenna interface.
Antenna connectors: GSC coaxial connector
Evaluation kit DSB 35 Support Box
Product Data
SIM Application Toolkit Supported
Half Rate (ETS 06.20)
Full Rate (ETS 06.10)
Speech codec:
Enhanced Full Rate (ETS 06.50 / 06.60 / 06.80)
Audio
Audio interface: 2 x analogue audio interfaces (hands-free, supports echo cancellation)
General: Point-to-point MT and MO SMS
SMS Cell Broadcast
Text and PDU mode SMS MO
Transmission of SMS:
Over CSD or GPRS connections.
Preferred mode can be user-defined.
SMS
SMS storages SIM + 25 places on ME
