Siemens MJ-4 Series Installation Manual

24
5 Band, VRC, VLC status
6 Tap Position
7 Load Current
8 Load Voltage
9 Load Voltage (primary)
10 Source Voltage
11 Source Voltage (primary)
12 KVA
13 KVAR
14 KW
15 Power Factor
Analog Outputs
Point # Description
0 Op Count Total
8.2.5 Simple
Binary Inputs
Point # Description
0 Auto Inhibit Status
1 Remote Switch position
2 Manual Switch position
Binary Outputs
Point # Description
0 Tap Raise
1 Tap Lower
2 Auto Inhibit (On/Off)
Analog Inputs
Point # Description
0 Tap Position
1 Load Voltage
2 Load Current
3 Source Voltage
Analog Outputs
No Analog Outputs in the Simple set currently.
8.2.6 Metering
Binary Inputs
Point # Description
0 LOW Voltage Limiting, [1=On]
1 HIGH Voltage Limiting, [1=On]
2 Automatic Operation, [1=Inhibited]
3 Power Flow Direction, [0=Fwd, 1=Rev]
4 R/A/M Switch, [0=Off/Manual, 1=Auto/Remote]
5 Voltage Reduction Input 1, [0=Open, 1=Closed]
6 Voltage Reduction Input 2, [0=Open, 1=Closed]
7 Supervisory Switch, [0=Off, 1=On (Remote)]
8 Neutral Position Status, [0=inactive, 1=active]
9 Low Battery Status, [0=inactive, 1=active]
10 Raise Limit Reached, [0=inactive, 1=active]
11 Lower Limit Reached, [0=inactive, 1=active]
