Replacing an HMI device
2.3 Interfaces
Migration Guide Comfort Panels
Getting Started, 03/2011, A5E03478626-01
17
The following figure shows the interfaces on the predecessor devices of the Comfort HMI
devices KP/TP700 Comfort to KP/TP1200 Comfort.

   
   
03
03.H\7RXFK
03.H\7RXFK
73%
73
23%
23
73&RPIRUW
73&RPIRUW
73&RPIRUW
.3&RPIRUW
.3&RPIRUW
.3&RPIRUW
① USB type A
The predecessor devices MP 277 8" and MP 277 10" have two USB type A connectors
② PROFINET (Ethernet)
③ PROFIBUS (Sub-D RS 422/485)
④ Mains
⑤ Connection for equipotential bonding (grounding)
⑥ USB type mini B
⑦ Audio Line IN / OUT
