7.4.6 Technical data
Memory for system data
Table 7-20
Diagnostic buffer
Data SIMOTION CX32
Diagnostic buffer (non-volatile) 100 messages
The data for the CX32 is stored exclusively on the SIMOTION D435/D445/D445‑1, which
means no action has be taken when the module is replaced.
Dimensions and weight
Table 7-21
Dimensions and weight of a SIMOTION CX32
Parameter SIMOTION CX32
Dimensions W x H x D [mm]
(max. expansion)
● Without fastening using spacers
● With fastening using spacers
● 25 x 380 x 230
● 25 x 380 x 270
Weight CX32 [g]
●
Without packaging
● With packaging
● approx. 2200
● approx. 2700
Ambient conditions
Table 7-22
CX32 environmental requirements
Parameter Values
Permissible ambient temperature
●
Storage and transport
● Operation
● -40° C ... +70° C
● 0° C to +55° C up to 2000 m above sea level
As of an altitude of 2000 m, the maximum ambient
temperature decreases by 7° C every 1000 m
Permissible relative humidity
(without condensation)
5 % ... 95 %
Installation altitude Max. 5,000 m above sea level
Organic/biological influences
●
Storage
● Transport
● Operation
● Class 1B1 according to EN 60 721‑3‑1
● Class 2B1 according to EN 60 721‑3‑2
● Class 3B1 according to EN 60 721‑3‑3
Pollution degree 2 according to EN 60 664‑1
Supplementary system components
7.4 Controller Extension CX32
SIMOTION D4x5
104 Manual, 04/2014
