References
You will find additional information in the following references:
Programming Manual Job Planning / SINUMERIK 840D sl / 828D
6.12.2 Global R parameters
Global R parameters are arithmetic parameters, which exist in the control itself, and can be
read or written to by all channels.
You use global R parameters to exchange information between channels, or if global settings
are to be evaluated for all channels.
These values are retained after the controller is switched off.
Comments
You can save comments in the "Global R parameters with comments" window.
These comments can be edited. You have the option of either individually deleting these
comments, or using the delete function.
These comments are retained after the control is switched off.
Number of global R parameters
The number of global R parameters is defined in a machine data element.
Range: RG[0]– RG[999] (dependent on the machine data).
There are no gaps in the numbering within the range.
Machine manufacturer
Please observe the information provided by the machine manufacturer.
Procedure
1. Select the "Parameter" operating area.
2. Press the "User variable" softkey.
3. Press the "Global R parameters" softkey.
The "Global R parameters" window opens.
Machining the workpiece
6.12 Display and edit user variables
Milling
240 Operating Manual, 08/2018, 6FC5398-7CP41-0BA0
