Spare Parts/Accessories
10.2 CompactFlash Card
NCU 7x0.2
104 Manual, 02/2011, 6FC5397-0AP20-0BA0
6. Push the plastic guide into the cutouts on the underside of the Control Unit.
7. Tilt the dual fan/battery module up until the front interlock snaps into place.
The electrical connection between the dual fan/battery module and the Control Unit is
established automatically.
NOTICE
To avoid loss of data, the dual fan/battery module must be replaced during operation.
When doing this, observe that the Control Unit can only be operated for a maximum of 1
minute without fans. If this time is exceeded, the Control Unit will shut itself down.
10.2 CompactFlash Card
10.2.1 Properties
Application
The CompactFlash Card is delivered bootable. It is not supplied with the control unit and
must be ordered as a separate component.
The CompactFlash Card is inserted in the CF plug-in slot (X109 interface).
CAUTION
The CompactFlash Card may only be inserted or removed when the control unit is
disconnected from the power supply.
Data
The CompactFlash Card is mandatory for operation of the control unit.
As well as the basic software for SINUMERIK and the firmware for SINAMICS, the
CompactFlash Card also contains:
● User data (programs, configuration data, parameter settings)
● Version info (serial number, version, type designation)
● License key This means that the CompactFlash Card can be inserted into another control
unit without requiring a license change.
