Connectable components
9.2 COM01.2 RS 232C (V.24) module
NCU 7x0.2
Manual, 02/2011, 6FC5397-0AP20-0BA0
95
9.1.5 Technical Data
Table 9- 10 Technical data
Parameters Values
Input voltage
Current (without DRIVE-CLiQ or digital outputs)
24 V DC (20.4 – 28.8)
0.8 A
PE/ground connection On housing with M5/3 Nm screw
Dimensions (WxHxD) 24.5 x 396 x 226 mm
Weight 1.5 kg
Mounting position Vertical
9.2 COM01.2 RS 232C (V.24) module
9.2.1 Description
The Option Board COM01.2 RS 232C (V.24) module can be inserted into the option slot on
the following control units:
● NCU 710.2
● NCU 720.2
● NCU 730.2
The control units can be connected to a master computer or modem via COM port X491.
The COM port has been designed in accordance with the "ANSI/EIA/TIA-232-F-1997"
standard.
