Technical data
84
SIPROTEC PROFIBUS-DP - Communication profile
C53000-L1840-B001-03
5.1 Connection via the PSE module
Connection 9-pole D-SUB outlet (ref. to Table 5-1)
Protocol semi-duplex
Max. line length
(depending on the
transmission rate)
9.6 kB/s 1000 m
19.2 kB/s 1000 m
93.75 kB/s 1000 m
187.5 kB/s 500 m
500.0 kB/s 200 m
1500.0 kB/s 200 m
6000.0 kB/s 100 m
Insulation level 500 V
AC
Bus termination On the PROFIBUS module: integrated, connectable terminating resistors
• 221 Ohm between RxD/TxD-P (B) and RxD/TxD-N (A)
• 392 Ohm between RxD/TxD-P (B) and VCC1 as well as RxD/TxD-N (A) and GND1.
Input resistance not terminated ≥ 10 kOhm, then bus termination via bus plug with
integrated terminating resistors
Level Transmitter:
• Low: -5 V ≤ V
A-B
≤ -1.5 V
• High: +5 V ≥ V
A-B
≥ +1.5 V
Receiver:
• Low: V
A-B
≤ -0.2 V
• High: V
A-B
≥ +0.2 V
Transmitter and receiver are surge-proof for voltages between A and GND1 as well as
between B and GND1 in the range of -7 V...+12 V.
Cable Bus cable type A according to EN 50170, twisted and screened.
SIMATIC NET PROFIBUS 6XV1 830
Plug SIMATIC bus connection plug for PROFIBUS 6GK1 500-0EA02 with axial cable out-
put, resistor combination integrated and connectable by sliding switch.
Dimensions (W x H x D) : 39 mm x 15 mm x 57 mm
Depth incl. cable bending radius : approx. 120 mm
Note:
When angle plugs or plugs with non-axial output are used then the direction of the out-
going cable has to be coordinated with neighboring terminals and plugs.
