PROFIBUS Communication modules
20
SIPROTEC PROFIBUS-DP - Communication profile
C53000-L1840-B001-03
MapNo. Number of the selected standard mapping.
The mapping file determines the data size which is available via PROFIBUS-DP for
the SIPROTEC device.
Depending on the device type, several standard mappings are offered for parameter-
ization in DIGSI (ref. to page 3, “Bus mapping documentation” for the individual
SIPROTEC devices).
MapRev. Version of the selected standard mapping with the number MapNo. (see above).
1.2.3 Block 3: Module hardware information and boot firmware version
Block 3 of the module-specific information contains hardware information for the built-
in communication module.
Module Hardware type of the communication module built-in in the SIPROTEC device:
HWCode A hardware designation, coded on the module, in hexadecimal representation.
HWRev. Hardware revision of the communication module.
BF-No. Serial number (production number) of the communication module.
Ld_Jmp Version of the separate boot firmware part for start-up and with loader functions.
Module Explanation Note
PSE_GEN PROFIBUS module RS485 OK
PSO2_GEN
PROFIBUS module fibre-optical, double loop
(with two fibre-optical channels)
OK
PSO1_GEN
PROFIBUS module fibre-optical, single loop
(with one fibre-optical channel)
not for PROFIBUS-DP,
please replace
AME_GEN Asynchronous module RS485
not for PROFIBUS-DP,
please replace
AMO-GEN Asynchronous module fibre-optical
not for PROFIBUS-DP,
please replace
Table 1-3 Communication module hardware types
