Singer 1732 User Manual

- Place the thread and Spool pin felt (a) onto the spool pin. (1)
- Wind thread clockwise around bobbin winder tension discs. (2)
- Thread bobbin as illustrated and place on spindle. (3)
- Push bobbin to right. (4)
- Hold thread end (5). Step on foot control pedal. (6)
- Cut thread (7). Press bobbin to left (8) and remove.
When the bobbin winder spindle is in "bobbin winding" position,
the machine will not sew and the hand wheel will not turn. To
start sewing, push the bobbin winder spindle to the left (sewing
position).
Please Note:
18
Winding the bobbin
GB
1
2
4
5
6
78
3
a

Singer 1732 Specifications

General

Type	Mechanical
Stitch Width	5mm
Built-in Stitches	32
Buttonhole Styles	1-step
Built-in Needle Threader	Yes
Free Arm	Yes
Stitch Options	decorative, stretch
Included Accessories	All-purpose foot, zipper foot, buttonhole foot, button sewing foot, seam ripper, needles, bobbins, screwdriver, spool pin felt
Dimensions	12 inches
