Singer M2100 User Manual

6
Winding the Bobbin
- Place the thread and spool pin felt (a) onto the spool pin. (1)
- Draw the thread from the spool through the upper thread
guide. (2)
- Wind the thread clockwise around bobbin winder tension
discs. (3)
- Thread bobbin as illustrated and place on spindle. (4)
- Push bobbin spindle to right. (5)
- Hold thread end. (6)
- Step on foot control pedal. (7)
- Release the pedal after a few turns. Release the thread
and cut as close as possible to the spool. Press the pedal
again. Once the spool is full, it rotates slowly. Release the
pedal and cut thread. (8)
- Push bobbin spindle to left (9) and remove.
Please Note:
When the bobbin winder spindle is in “bobbin winding”
position, the machine will not sew and the hand wheel will
not turn. To start sewing, push the bobbin winder spindle
to the left (sewing position).
a
Threading the Machine

Singer M2100 Specifications

General

Buttonhole Style	4-step
Presser Foot Lifter	Yes
Free Arm	Yes
Type	Mechanical
Stitch Width	5 mm
Bobbin Type	Front-loading
Buttonhole Styles	1
Built-in Needle Threader	No
Drop-in Bobbin	No
Maximum Stitch Length	4 mm
Stitch Applications	Stretch
Presser Feet Included	All-Purpose Foot, Buttonhole Foot, Zipper Foot
Weight	12.1 lbs (5.5 kg)
