Singer M2100 User Manual

7
When inserting or removing the bobbin, the needle must
be fully raised.
- Open the hinged cover. (1)
- Pull the bobbin case tab (a) and remove the bobbin case.
(2)
- Hold the bobbin case with one hand. Insert the bobbin so
that the thread runs in a clockwise direction (arrow). (3)
- Pull the thread through the slit and under the nger. Leave
a 6 inch tail of thread. (4)
- Hold the bobbin case by the hinged latch. (5)
- Insert it into the shuttle. (6)
Attention:
Turn power switch to o󰀨 (“O”) before inserting or removing
the bobbin.
Inserting the Bobbin

Singer M2100 Specifications

General

Buttonhole Style	4-step
Presser Foot Lifter	Yes
Free Arm	Yes
Type	Mechanical
Stitch Width	5 mm
Bobbin Type	Front-loading
Buttonhole Styles	1
Built-in Needle Threader	No
Drop-in Bobbin	No
Maximum Stitch Length	4 mm
Stitch Applications	Stretch
Presser Feet Included	All-Purpose Foot, Buttonhole Foot, Zipper Foot
Weight	12.1 lbs (5.5 kg)
