9
Hold the upper thread with the left hand. (1)
Turn the handwheel towards you (counterclockwise) lowering,
then raising needle.
Note:
If it is di󰀩cult to raise the bobbin thread, check to make
sure the thread is not trapped by the hinged cover or the
Removable Extension Table.
Raising the Bobbin Thread
Gently pull on the upper thread to bring the bobbin thread up
through the needle plate hole. (2)
Lay both threads to the back under the presser foot. (3)

Singer M2100 Specifications

General

Buttonhole Style	4-step
Presser Foot Lifter	Yes
Free Arm	Yes
Type	Mechanical
Stitch Width	5 mm
Bobbin Type	Front-loading
Buttonhole Styles	1
Built-in Needle Threader	No
Drop-in Bobbin	No
Maximum Stitch Length	4 mm
Stitch Applications	Stretch
Presser Feet Included	All-Purpose Foot, Buttonhole Foot, Zipper Foot
Weight	12.1 lbs (5.5 kg)
