SEWING
On your overlock machine, different stitches are obtained by combining different needle positions, threading methods, tension
settings, and the use of the 2-thread overlock converter.
See Getting Ready to Sew, page 7, for references on how to set your machine.
Stitch Overview
The settings shown in the table below are our recommendations based on normal conditions. It may be necessary to adjust the
thread tension depending on the stitch, type of fabric and thread you are using. For best results make tension adjustments in small
increments of no greater than half a number at a time. Always test sew on a sample of your fabric before sewing on your project.
In the table below, different fabric weights and types are explained. For you to better understand how the stitches are formed, each
of the threads are displayed in different shades of grey.
Icon Explanation Sheet
Woven light
Chiffon, voile, organza, batiste, silk, etc.
Needle position
2–thread overlock converter
Woven medium
Cotton, chino, wool, satin, etc.
Differential feed
Right needle thread
Woven heavy
Denim, canvas, terrycloth, etc.
Stitch length
Left needle thread
Stretch light
Charmeuse, nylon, tricot, single knit
jerseys, etc.
Cutting width Upper looper thread
Stretch medium
Double knit, velour, swimwear, etc.
N/R
Stitch finger position
Lower looper thread
Stretch heavy
Sweater knits, fleece, etc.
4–Thread Overlock
For all seams where stretch or give is needed, such as neck edges, side seams, sleeves, etc.
Stitch/Fabric N/R
Thread Tension
Both 1.0 3 5~6 N — 3 3 4 4
Both 1.0 3 5~6 N — 4 4 4 4
Both 1.0 3~4 5~6 N — 4 4 4 4
Both 1.0 3 5~6 N — 4 4 4 4
Both 1.0 3 5~6 N — 4 4 4 4
Both 1.0 3~4 5~6 N — 4 4 4 4
Sewing – 15
English
