15.1.2 P/NS OF MATING CONNECTOR (CRIMP VERSION)
MFR
MFR P/N
DESCRIPTION
QTY
Conec
3005W1SXK99A10X
Conec Connector Shell w/o contacts
1
Conec
132C15019X
Conec Crimp signal contact
4
Conec
132C11029X
Conec Crimp Power Contact
1
Conec
165X13369X
Conec Plastic Back Shell
1
15.1.3 P/NS OF MATING CONNECTOR (SOLDER CUP VERSION)
MFR
MFR P/N
DESCRIPTION
QTY
Conec
3005W1SCM99A10X
Conec Connector Shell incl. signal contacts (solder
cup)
1
Conec
132C10029X
Conec Power Contact (Solder cup)
1
Conec
165X13369X
Conec Plastic Back Shell
1
15.2 RS232 (DB9) FOR BLUETOOTH
PIN #
CONNECTION
1
DCD
2
RxD
3
TxD
4
DTR
5
GND
6
DSR
7
RTS
8
CTS
9
150mA power supply for Bluetooth dongle Parani SD100/200 or similar
NOTE: Some Bluetooth adapters may require the use of a null modem.
