SMC Networks HRSH250-W*-20 Series User Manual

HRX-OM-Q026
Chapter 3 Transport and Setting Up
3.2 Installation HRSH Series
3-8
 Required facility water system (for water cooled type)
Table 3-3 Heat radiation
Model
Heat
radiation
(kW)
Facility water specifications
HRSH100-W-20/40-
Approx. 20
Refer to “8.1 Specifications”.
HRSH150-W-20/40-
Approx. 27
HRSH200-W-20/40-
Approx. 34
HRSH250-W-20/40-
Approx. 40
 Installation at indoor site
The product’s splash-proof specification is IPX4.
 Installation environment specifications
Sound noise:HRSH300-A- : 71dB(A)
HRSH100/150/200/250-A- : 68dB(A)
HRSH150/200-W- : 60dB(A)
HRSH100/250-W- : 61dB(A)
* Front 1m, height 1m, rated condition
The water cooled product radiates heat to the facility water.
It is necessary to supply the facility water. Please prepare the facility
water system that satisfies the heat radiation and the facility water
specifications below.
