2.2 General Specifications
 Motor Type: AC Asynchronous 3-Phase
 Braking: Regenerative
 Modulation: PWM (Pulse Width Modulation)
 Switching Frequency: 9kHz
 Low R
DS,on
MOSFET
 16 bits DSP controlling 1 AC motor
 Integrated Hall Effect Current Sensors
2.3 Electrical Specifications
2.3.1 Input and Output Ratings
Model Chart for 24V version
Model Name
AC Inverter Max Arms(2’)
Max Power(2’) at 24V
AC-M1 24V 350A
350 A
rms
9.7kVA
AC-M1 24V 450A
450 A
rms
12.5 kVA
Model Chart for 36/48V version
Model Name
AC Inverter Max Arms(2’)
Max Power (2’) at 48V
AC-M1 36/48V 375A
375 A
rms
20.8 kVA
AC-M1 36/48V 500A
500 A
rms
27.5 kVA
Model Chart for 72/80V version
Model Name
AC Inverter Max Arms(2’)
Max Power (2’) at 80V
AC-M1 72/80V 350A
350 A
rms
32.3 kVA
AC-M1 72/80V 450A
450 A
rms
41.6 kVA
