Product description
Confirm the logout process by pressing
T.
In the case you want to cancel the logout process press
U.
This will bring you back to the main menu.
Login
After the initial boot sequence or after logging out a user ( 24,
chapter “ Logout“) the login screen is displayed (see Fig. 25).
The default user logins are:
User User role Note
Operator 135 Primarily used at the local sta-
tion.
246
Operator male 2110 Primarily used at the remote sta-
tion.
Operator female 3110
The login data is entered by using the function keys and the nav-
igator . Fig. 26 shows a detail of the keyboard's function keys.
Important!
Inside an input field the lower-case numbers and letters
[1 abc] ... [0 _.] written above each function key are act-
ive. This gives the operator the ability to enter letters
and numbers. The numbers are used by default. To
switch between the entry of letters and numbers press
/ Q.
You can delete wrong text entries by moving the cursor
to the left using the navigator.
After a successful login, the main screen is displayed. Depending
on the user login the viewing window can have a different look (
21).
95591706 11/02/2010 © smiths detection proprietary information
Fig. 24: Logout confirmation screen
Fig. 25: Login screen
Fig. 26: Function keys and navigator
25
