26
Specifications
Specifications
The following specifications show the reference
performance for this unit and individual option boards/
modules.
Design and specifications are subject to change without
notice.
Center Control Panel
The center control panel is comprised of the main panel,
the System Control Unit (MKS-8010/8010A), the menu
panel (MKS-8011), and operation modules. The required
operation modules are installed in the main panel at the
factory.
The following accessories are center control panel
accessories.
Accessories supplied
75Ω terminator (1)
T bridge (1)
Button top puller (1)
50-pin cables*
Name plates (attached to main panel)
USB cable (5 m/16 ft) (1)
Track ball (1)
Switch cover 12 (20)
Switch cover 15 (20)
Self-lighting switch chip (5)
Operation Manual (1)
Installation Manual (1)
User’s Guide (2)
Software License Agreement (1)
∗ The number depends on the system configuration.
When purchased together with the center control panel,
the MKS-8075 Extension Adaptor and MKS-8076 Memory
Card/USB Adaptor are supplied with the same accessories
as when purchased separately (see page 32).
Main Panel
Main panel specifications vary according to the system
configuration. The following shows specifications for
typical configurations.
General
Power requirements
12 V DC
Power consumption
Max. 10 A
Operating temperature
5ºC to 40ºC (41ºF to 104ºF)
Performance temperature
10ºC to 35ºC (50ºF to 95ºF)
Storage temperature
−20ºC to +60ºC (−4ºF to +140ºF)
Operating humidity
10% to 90%
Dimensions* (w/h/d)
Example 1: (32 crosspoint buttons, 4 M/
E): 1443×98×528 mm
(56
7
/
8
×3
7
/
8
×20
7
/
8
inches)
Example 2: (32 crosspoint buttons, 3 M/
E): 1223×95×528 mm
(48
1
/
4
×3
3
/
4
×20
7
/
8
inches)
Example 3: (32 crosspoint buttons, 2 M/
E): 1443×92×396 mm
(56
7
/
8
×3
5
/
8
×15
5
/
8
inches)
Example 4: (32 crosspoint buttons, 2 M/
E): 1223×92×396 mm
(48
1
/
4
×3
5
/
8
×15
5
/
8
inches)
Example 5: (24 crosspoint buttons, 4 M/
E): 1291×98×528 mm
(50
7
/
8
×3
7
/
8
×20
7
/
8
inches)
Example 6: (24 crosspoint buttons, 3 M/
E): 1071×98×528 mm
(42
1
/
4
×3
7
/
8
×20
7
/
8
inches)
Example 7: (24 crosspoint buttons, 2 M/
E): 1291×92×396 mm
(50
7
/
8
×3
5
/
8
×15
5
/
8
inches)
Example 8: (24 crosspoint buttons, 2 M/
E): 1071×92×396 mm
(42
1
/
4
×3
5
/
8
×15
5
/
8
inches)
Mass* Example 1: Approx. 30 kg (66 lb 2 oz)
Example 2: Approx. 26 kg (57 lb 5 oz)
Example 3: Approx. 23 kg (50 lb 11 oz)
Example 4: Approx. 19 kg (41 lb 14 oz)
Example 5: Approx. 28 kg (61 lb 11 oz)
Example 6: Approx. 23 kg (50 lb 11 oz)
Example 7: Approx. 21 kg (46 lb 4 oz)
Example 8: Approx. 16 kg (35 lb 4 oz)
∗ Dimensions and mass vary depending on the configuration. The above
examples give dimensions (w/h/d) and mass for typical configurations.
For details, refer to the Installation Manual.
Control connectors
SCU D-sub 50-pin, female
HOST USB Type B
DEVICE USB Type A (2)
Maximum supply current 400 mA
