6-9
DCR-HC39E/HC41/HC42/HC42E/HC43/HC43E
3. A Page table
Note 1: Check that the data of page: 0, address: 10 is“00”.
Note 2: Fixed data-1: Initialized data. (Refer to“1. Initializing the
A, B, D, 1A, 1B Page Data”)
Fixed data-2: Modified data. (Refer to“2. Modification
of A, B, D, 1A, 1B Page Data”)
Address
Initial value
Remark
NTSC PAL
10 00 00 Test mode
11 to 17 Fixed data-1 (Initialized data)
18 Fixed data-2
19 Fixed data-1 (Initialized data)
1A Fixed data-2
1B to 2E Fixed data-1 (Initialized data)
2F
30
31
Fixed data-2
32
33 to 60 Fixed data-1 (Initialized data)
61
62
63 Fixed data-2
64
65
66 Fixed data-1 (Initialized data)
67 Fixed data-2
68 to 8F Fixed data-1 (Initialized data)
90 EA EA
91 0F 0F
92 C7 C7
Touch panel adj
93 2A 2A
94 to 97 Fixed data-1 (Initialized data)
98
99
9A
9B Fixed data-2
9C
9D
9E
9F to CF Fixed data-1 (Initialized data)
D0
D1 Fixed data-2
D2
D3, D4 Fixed data-1 (Initialized data)
D5 Fixed data-2
D6 Fixed data-1 (Initialized data)
D7 Fixed data-2
D8 Fixed data-1 (Initialized data)
D9 Fixed data-2
DA to F0 Fixed data-1 (Initialized data)
F1 Fixed data-2
Address
Initial value
Remark
NTSC PAL
F2
F3
Fixed data-2
F4 to FF Fixed data-1 (Initialized data)
4. B Page table
Note 1: Check that the data of page: 0, address: 10 is “00”.
Note 2: Fixed data-1: Initialized data. (Refer to “1. Initializing
the A, B, D, 1A, 1B Page Data”)
Fixed data-2: Modified data. (Refer to “2. Modification
of A, B, D, 1A, 1B Page Data”)
Address
Initial value
Remark
NTSC PAL
00 to FF Fixed data-1 (Initialized data)
To Next Page
