Hookups
19
Step 2: Connecting the Audio Cords
Refer to the chart below to select the connection that best suits your system. The surround effects
you will enjoy depend on the connections and components you use.
Select one of the following connections, through .
* Manufactured under license from Dolby Laboratories. “Dolby,” “Pro Logic,” and the double-D symbol are
trademarks of Dolby Laboratories. Confidential unpublished works. © 1992-1997 Dolby Laboratories. All rights
reserved.
** “DTS” is a registered trademark of Digital Theater Systems, Inc.
Select a connection
Connection Components to be connected
(page 20)
• TV (stereo)
(page 21)
• AV amplifier (receiver) having 5.1ch input jacks
• 4 speakers
(front L and R, rear L and R)
• 6 speakers
(front L and R, center, rear L and R, subwoofer)
(page 21)
• AV amplifier (receiver) having a Dolby
*
Digital or DTS
**
decoder and a digital
input jack
• 6 speakers
(front L and R, center, rear L and R, subwoofer)
(page 23)
• Stereo amplifier (receiver)
(having L and R audio input jacks only, or having a digital input jack)
• 2 speakers
(front L and R)
(page 23)
• MD deck/DAT deck
(page 24)
• AV amplifier (receiver) with a Dolby Surround (Pro Logic) decoder
(having L and R audio input jacks only, or having a digital input jack)
• 3 speakers
(front L and R, and rear (monaural))
• 6 speakers
(front L and R, center, rear L and R, subwoofer)
A
D
A
B
B
C
C
D
continued
To Next Page
