1-7-2. Matching Connectors and Cables
When external cables are connected to the connector of this unit, the hardware listed below (or equiva-
lents) must be used.
Panel indication Matching connector (cable) Sony part No. Remarks
AUDIO INPUT XLR 3P, MALE 1-508-084-00 Recorder only
CUE IN
TIME CODE IN
AUDIO OUTPUT XLR 3P, FEMALE 1-508-083-00
CUE OUT
MONITOR OUT
TIME CODE OUT
REF INPUT BNC 75Z, MALE 1-569-370-12
VIDEO INPUT
VIDEO OUTPUT
AUDIO INPUT (AES/EBU) BNC 75Z, MALE
*1
1-569-370-12
AUDIO OUTPUT (AES/EBU)
REMOTE 2 D-SUB 50P, MALE and 1-565-516-11
PARALLEL I/O (50P) JUNCTION SHELL 50P 1-563-379-11
REMOTE 1-IN (9P) 9P remote control cable (RCC-G series) _
REMOTE 1-OUT (9P) or or
D-SUB 9P, MALE and 1-560-651-00
JUNCTION SHEEL 9P 1-561-749-00
RS-232C D-SUB 9P, FEMALE 1-563-815-21
CONTROL PANEL 10P, MALE 1-792-418-11/BKMW-103 (10 m, available separately)
(exclusive connecting cable)
VIDEO CONTROL (15P) D-SUB 15P, FEMALE and 1-561-610-21
JUNCTION SHELL 15P 1-561-929-00
VIDEO CONTROL (9P) D-SUB 9P, MALE and 1-561-651-00 HDW series only
JUNCTION SHELL 9P 1-561-749-00
(OPTION) Specified by optional kit _ DVW/MSW series only
or
D-SUB 9P, MALE and 1-560-651-00
JUNCTION SHEEL 9P 1-561-749-00
HD SDI BNC 75Z, MALE
*2
1-569-370-12 HDW series only
SDI BNC 75Z, MALE
*3
1-569-370-12
SDTI-CP
SDTI (OPTION)
Ethernet
*5
Cable compliant with 1000BASE-T standard MSW-M2000E/M2000EP/M2100E/M2100EP only
(UTP cable: Category 5e and higher)
*4
PHONE JM-60 stereo phone plug _ Upper control panel connector
*1: Coaxial cable length : max. 600 meters (Reference value based on HDW/DVW/MSW series)
It is recommended to connect the BELDEN 8281 cable or equivalent to this connector.
*2: Coaxial cable length : max. 100 meters (Reference value based on HDW series)
It is recommended to connect the BELDEN 1694A cable or equivalent to this connector.
*3: Coaxial cable length : max. 200 meters (Reference value based on HDW/DVW/MSW series)
It is recommended to connect the BELDEN 8281 cable or equivalent to this connector.
*4: Coaxial cable length : max. 100 meters
A category 5 cable can only be used for 100BASE-TX communication.
*5: Ethernet is a registered trademark of Xerox corporation.
