1-1
HDW-2000/M2000/M2000P/S2000/S2000P/M2100/M2100P, DVW-2000/2000P/M2000/M2000P
MSW-2000/A2000/A2000P/M2000/M2000P/M2000E/M2000EP/M2100/M2100P/M2100E/M2100EP
1-3. Operating Conditions
1-4. Power Supply
1-5. Installation Space
1-6. Rack Mounting
1-7. Connection
1-8. Signal Inputs and Outputs
1-9. Switch Settings on Connector
Panel
1-10. Switch Settings on Circuit
Boards
1-11. Operation Mode Settings
(For DVW-2000/M2000 only)
1-12. Removing/Reattaching
Lower Control Panel Unit
1-13. Switching Search Dial Mode
1-14. Reference System
1-15. Settings and Adjustment
when External Equipment
is Connected
Start
Determination of
installation place
Unpacking
Rack mounting
*Connection
*Initial setup
*Operation check
End
n
If an error message appears on the time data
display area, refer to the operation manual.
(For more details, refer to the maintenance
manual volume-1.)
n
When the unit is transported, it is required to
pack the unit into the specified new packing
materials.
Do not reuse the packing materials.
Section 1
Installation
1-2. Supplied Accessories
. Screws for rack mounting (PSW 4 x 16) ....................... 4
. Clamp filters (HDW series only) ............................ 4 or 6
. Operation manual
Japanese
*1
................................................................... 1
English ........................................................................ 1
. Operation manual CD-ROM (PDF) ............................... 1
. Installation manual
Japanese
*1
.................................................................... 1
English ........................................................................ 1
. Operation manual & application software CD-ROM
(PDF)
*2
........................................................................... 1
. BKMW-E3000 Installation manual
*2
............................. 1
*1: Supplied with DVW series only.
*2: Supplied with MSW-M2000E/M2000EP/M2100E/
M2100EP only.
1-3. Operating Conditions
c
Good air circulation is essential to prevent internal heat build-
up. Place the unit in location with sufficient air circulation.
Do not block the ventilation holes of the cabinet and the
front and rear panels.
Operating temperature: 5 dC to 40 dC
Operating humidity: 25 % to 80 % (non-condensing)
Storage temperature: _20 dC to 60 dC
Locations to avoid:
. Areas where the unit will be exposed to direct sunlight
of any other strong lights.
. Areas near heat sources.
. Dusty areas or areas subject to vibration.
. Areas with strong magnetic field.
. Areas with much electrical noise.
. Areas with much static electricity.
. Areas that is impossible to find a specified room for
installation. (Refer to “1-5. Installation Space”.)
. Areas windtight.
Tilt allowance: Within 30d (Do not slant the front
and rear of the unit more than 30d.)
c
Fix the unit securely to avoid drop when the unit is operat-
ed at not-horizontal place.
1-1. Installation Procedure
Installation procedure of this unit is shown on the follow-
ing flowchart.
Refer to each section about detail of each flow.
The operation manual is also required to do *-marked
flow.
To Next Page
