14
(1) Install the power source.
(2) Slide OPEN/ZEJECT in the direction of the arrow and open the lid.
The cassette compartment automatically lifts up and opens.
(3) Push the middle portion of the back of the cassette to insert.
Insert the cassette in a straight line deeply into the cassette compartment with
the window facing out.
(4) Close the cassette compartment by pressing the
mark on the cassette
compartment. The cassette compartment automatically goes down.
(5) After the cassette compartment going down completely, close the lid until it
clicks.
To eject a cassette
Follow the procedure above, and take out the cassette in step 3.
Notes
•Do not press the cassette compartment down forcibly. Doing so may cause
malfunction.
•The cassette compartment may not be closed when you press any part of the lid other
than the mark.
When you use mini DV cassette with cassette memory
Read the instruction about cassette memory to use this function properly (p. 138).
To prevent accidental erasure
Slide the write-protect tab on the cassette to expose the red mark.
Step 2 Inserting a cassette
3, 4
5
2
OPEN/ZEJECT
3
4
To Next Page
