HBD-TZ210/TZ230/TZ510/TZ630/TZ710
18
2-15. OPTICAL PICK-UP
2 FFC holder
3 two insulator screws
4 two insulator screws
5 two insulators
6 two insulators
7 optical pick-up
(KHM-313CAA)
1 two claws
