63
HBD-TZ210/TZ230/TZ510/TZ630/TZ710
101 3-077-331-21 +BV3 (3-CR)
102 1-828-322-11 WIRE (FLAT TYPE) (11 CORE)
103 A-1746-214-A FL BOARD, COMPLETE
104 1-828-955-11 WIRE (FLAT TYPE) (9 CORE)
105 3-703-244-00 BUSHING, CORD (2104) (EXCEPT TH)
105 4-916-783-01 BUSHING, CORD (TH)
0
106 1-834-288-12 CORD, POWER (TH)
0
106 1-834-966-41 CORD, POWER-SUPPLY
(E3,E12,E32,PH,RU,SAF,SP,AEP)
0
106 1-835-068-21 CORD, POWER (AUS)
0
106 1-835-078-31 CORD, POWER (EA,HK,UK)
0
106 1-837-308-11 CORD, POWER-SUPPLY (CND)
0
106 1-837-312-11 CORD, POWER-SUPPLY (AR)
0
106 1-837-344-11 CORD, POWER-SUPPLY (MX)
0
106 1-837-345-11 CORD, POWER-SUPPLY (TW)
0
106 1-837-822-21 CORD, POWER-SUPPLY (CH)
0
107 1-569-008-33 ADAPTOR, CONVERSION (E32)
108 3-077-331-11 +BV3 (3-CR)
109 1-823-718-11 WIRE (FLAT TYPE) (17 CORE) (TZ230/TZ630)
ND5000 1-483-107-11 FLUORESCENT INDICATOR TUBE
TU401 1-693-780-21 TUNER (FM) (ANTENNA)
(EXCEPT CND,RU,SAF,AEP,UK,CH)
TU401 1-693-781-21 TUNER (FM) (ANTENNA) (CND)
TU401 1-693-788-21 TUNER (FM) (ANTENNA) (RU,SAF,AEP,UK,CH)
#2 7-682-547-04 SCREW +B 3X6
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
6-3. FRONT BOARDS SECTION
Note:
If the wire (
fl
at type) was replaced, fold it some as the
wire (
fl
at type) before replacement.
107
109
105
106
#2
TU401
not supplied
(TZ210/TZ510/TZ710)
chassis section
not supplied
not supplied
TZ230/TZ630
not supplied
not supplied
not supplied
not supplied
(USB board)
not supplied
(SCART board)
not supplied
(USB-KEY board)
ND5000
101
108
108
108
108
108
108
101
101
102
103
104
101
Ver. 1.1
