Sony HBD-TZ715 Service Manual

HBD-TZ215/TZ715
17
2-14. DC MOTOR (LOADING) (M001), MS-203 BOARD
2-15. HOW TO BEND WIRE (FLAT TYPE)
2 three claws
6 MS-203 board
red
black
4 two solders
1 screw
(M1.7 u 2.5)
3
5 DC motor (loading)
(M001)
ZLUHIODWW\SHFRUHOHQJWKPP5HI1R
ZLUHIODWW\SHFRUHOHQJWKPP5HI1R
The upper side
is terminal side.
The upper side
is terminal side.
: Mountain fold
: Valley fold
198 mm
18 mm
25 mm27 mm
FL board
(CN5005)
MAIN board
(CN506)
TUNER (FM)
MAIN board
(CN4000)
MAIN board
(CN1202)
MAIN board
(CN1101)
12 mm
ZLUHIODWW\SHFRUHOHQJWKPP5HI1R
IOH[LEOHIODWFDEOH3OHQJWKPP5HI1R
CDM85 (MB) assy
50 mm
13 ± 0.5 mm
optical pick-up
(KHM-313CAA)
The lower side
is terminal side.
The lower side
is terminal side.
The lower side
is terminal side.
The lower side
is terminal side.
12 mm 12 mm
The upper side
is terminal side.
137 mm
10 mm
The upper side
is terminal side.
