Sony HBD-TZ715 Service Manual

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HBD-TZ215/TZ715
64
D2101 6-503-018-01 DIODE DZ2J08200L
D2102 6-501-592-01 DIODE EDZCTE616.8B
D2103 6-501-592-01 DIODE EDZCTE616.8B
D4002 6-502-961-01 DIODE DA2J10100L
D4004 6-502-961-01 DIODE DA2J10100L
D9712 6-502-961-01 DIODE DA2J10100L
< FERRITE BEAD >
FB471 1-500-283-11 INDUCTOR, FERRITE BEAD
* FB1106 1-400-973-21 INDUCTOR (EMI FERRITE)
* FB1107 1-400-973-21 INDUCTOR (EMI FERRITE)
* FB1108 1-400-973-21 INDUCTOR (EMI FERRITE)
* FB1109 1-400-973-21 INDUCTOR (EMI FERRITE)
* FB1111 1-400-974-21 INDUCTOR (EMI FERRITE)
* FB1112 1-400-974-21 INDUCTOR (EMI FERRITE)
* FB1113 1-400-974-21 INDUCTOR (EMI FERRITE)
* FB1115 1-400-974-21 INDUCTOR (EMI FERRITE)
* FB1116 1-400-974-21 INDUCTOR (EMI FERRITE)
* FB1117 1-400-974-21 INDUCTOR (EMI FERRITE)
* FB1118 1-400-974-21 INDUCTOR (EMI FERRITE)
* FB2101 1-400-973-21 INDUCTOR (EMI FERRITE)
* FB2103 1-400-973-21 INDUCTOR (EMI FERRITE)
FB2104 1-469-379-11 FERRITE, EMI (SMD) (2012)
FB2105 1-469-379-11 FERRITE, EMI (SMD) (2012)
FB2120 1-469-118-21 FERRITE, EMI (SMD) (1608)
FB2121 1-469-118-21 FERRITE, EMI (SMD) (1608)
FB2122 1-469-118-21 FERRITE, EMI (SMD) (1608)
FB2125 1-469-118-21 FERRITE, EMI (SMD) (1608)
FB2126 1-500-283-11 INDUCTOR, FERRITE BEAD
< IC >
IC307 8-759-680-48 IC TC7WH157FK
IC400 6-703-622-01 IC MM1508XNRE
IC401
8-759-430-37 IC MC14052BDTR2
IC403 6-712-744-01 IC TK11190CSCL-G
IC404 6-710-554-01 IC PCM1808PWR
IC471 6-707-853-01 IC TC74LCX541FT (EKJ)
IC503 A-1748-165-A IC R5F364AEDFA (for SERVICE)
IC504 6-716-462-01 IC BD00GA3WEFJ-E2
IC506 6-705-203-01 IC S-80935CNMC-G85T2G
IC507 (Not supplied) IC MM1665AHBE
IC509 6-712-613-01 IC SI-3010KM-TLS
IC510 6-709-584-01 IC MM1663DHBE
IC1101 6-714-722-01 IC CXD9927R-B
IC1102 6-717-861-01 IC MX29LV320EBTI-70-OHI-1201UC
(TZ215: E32)
IC1102 6-717-862-01 IC MX29LV320EBTI-70-OHI-1201CE
(TZ215: E3, E12/TZ715)
IC1103 6-717-889-01 IC M24C64-WMN6T (C)
IC1104 6-716-354-01 IC W9864G6JH-6-ER10
IC1105 6-715-134-01 IC MM3404A33URE
IC1107 6-715-134-01 IC MM3404A33URE
IC1110 6-707-739-01 IC MM1661JTRE
IC1501 (Not supplied) IC BD8203EFV-E2
IC1705 8-759-592-47 IC TC7SZ08FU (TE85R)
IC1707 6-717-756-01 IC RP173N501B-TR-FE
IC1708 6-717-755-01 IC RP173N331B-TR-FE
IC3000 6-713-634-01 IC CXD9965TN
IC3001 6-705-979-01 IC CXD9788AR
IC3002 6-713-634-01 IC CXD9965TN
IC3003 6-705-979-01 IC CXD9788AR
IC3004 6-713-634-01 IC CXD9965TN
IC3005 6-705-979-01 IC CXD9788AR
IC3006 6-714-743-01 IC MM3404A18URE
IC3007 6-706-492-01 IC TC7SHU04FU
< JACK >
J400 1-822-338-11 JACK, PIN 3P (VIDEO OUT, TV AUDIO IN)
< COIL >
L400 1-469-525-91 INDUCTOR 10uH
L401 1-469-525-91 INDUCTOR 10uH
L402 1-469-525-91 INDUCTOR 10uH
L403 1-469-525-91 INDUCTOR 10uH
L471 1-469-527-91 INDUCTOR 47uH
L1802 1-414-840-11 INDUCTOR 10nH
L1803 1-414-840-11 INDUCTOR 10nH
L3000 1-457-579-11 INDUCTOR 10uH
L3001 1-457-579-11 INDUCTOR 10uH
L3006 1-457-579-11 INDUCTOR 10uH
L3011 1-457-579-11 INDUCTOR 10uH
L3016 1-457-579-11 INDUCTOR 10uH
L3017 1-457-579-11 INDUCTOR 10uH
L3018 1-469-525-91 INDUCTOR 10uH
L3019 1-469-525-91 INDUCTOR 10uH
L3020 1-469-525-91 INDUCTOR 10uH
< TRANSISTOR >
Q400 8-729-029-06 TRANSISTOR DTC124EUA-T106
Q501 8-729-620-13 TRANSISTOR 2SC4154TP-1EF
Q1101 6-552-279-01 FET RT3K66M-T111-1
Q1102 6-550-653-01 TRANSISTOR QST8TR
Q1103 8-729-029-06 TRANSISTOR DTC124EUA-T106
Q1701 6-552-279-01 FET RT3K66M-T111-1
Q2101 6-551-272-01 TRANSISTOR RT3CLLM
Q3003 6-551-272-01 TRANSISTOR RT3CLLM
Q3004 8-729-620-13 TRANSISTOR 2SC4154TP-1EF
Q3005 6-552-772-01 TRANSISTOR RT3AMMAM1-T111-1F
Q3007 6-552-772-01 TRANSISTOR RT3AMMAM1-T111-1F
Q3009 6-552-772-01 TRANSISTOR RT3AMMAM1-T111-1F
Q3011 6-552-772-01 TRANSISTOR RT3AMMAM1-T111-1F
Q3013 6-552-772-01 TRANSISTOR RT3AMMAM1-T111-1F
Q3015 6-552-772-01 TRANSISTOR RT3AMMAM1-T111-1F
Q9730 6-551-714-01 FET INK0001AC1-T112-1
< RESISTOR >
R316 1-216-801-11 METAL CHIP 22 5% 1/10W
R317 1-216-801-11 METAL CHIP 22 5% 1/10W
R318 1-216-801-11 METAL CHIP 22 5% 1/10W
R319 1-216-801-11 METAL CHIP 22 5% 1/10W
R403 1-216-864-11 SHORT CHIP 0
R404 1-216-864-11 SHORT CHIP 0
R406 1-216-809-11 METAL CHIP 100 5% 1/10W
R409 1-216-809-11 METAL CHIP 100 5% 1/10W
R410 1-216-809-11 METAL CHIP 100 5% 1/10W
R411 1-211-990-11 METAL CHIP 75 0.5% 1/10W
R412 1-216-809-11 METAL CHIP 100 5% 1/10W
R413 1-216-809-11 METAL CHIP 100 5% 1/10W
R414 1-216-837-11 METAL CHIP 22K 5% 1/10W
MAIN
Note: IC507 and IC1501 on the MAIN board cannot exchange with single. When
these parts are damaged, exchange the complete mounted board.
