Sony HBD-TZ715 Service Manual

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HBD-TZ215/TZ715
68
C973 1-114-325-11 CERAMIC CHIP 0.1uF 10% 25V
C975 1-114-325-11 CERAMIC CHIP 0.1uF 10% 25V
C976 1-126-933-11 ELECT 100uF 20% 16V
0 C981 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C983 1-100-756-91 CERAMIC CHIP 0.047uF 10% 50V
C984 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C990 1-114-325-11 CERAMIC CHIP 0.1uF 10% 25V
C991 1-114-325-11 CERAMIC CHIP 0.1uF 10% 25V
C992 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C993 1-114-325-11 CERAMIC CHIP 0.1uF 10% 25V
0 C994 1-112-869-51 CERAMIC 470PF 10% 250V
C997 1-116-078-11 CERAMIC CHIP 1uF 10% 50V
0 C998 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
< CONNECTOR >
CN901 1-564-321-00 PIN, CONNECTOR (3.96mm PITCH) 2P
CN904 1-785-102-11 PIN, CONNECTOR (3.96mm PITCH) 4P
* CN906 1-764-334-11 PLUG, CONNECTOR 11P
< DIODE >
0 D901 8-719-082-57 DIODE D5SBA60F01
0 D902 8-719-063-74 DIODE D1NL20U-TR2
0 D906 6-502-961-01 DIODE DA2J10100L
0 D907 6-502-961-01 DIODE DA2J10100L
0 D908 6-502-961-01 DIODE DA2J10100L
0 D909 6-502-961-01 DIODE DA2J10100L
0 D910 6-502-961-01 DIODE DA2J10100L
0 D913 6-500-241-01 DIODE SARS03
0 D914 6-502-961-01 DIODE DA2J10100L
D931 6-501-849-01 DIODE FMX-22SL
D942 6-502-518-01 DIODE 50PQSA065-FA9
D943 8-719-080-53 DIODE RK36LF-B3
0 D946 8-719-030-25 DIODE EG01CV0
D954 8-719-080-59 DIODE EK19-V0
D955 8-719-080-59 DIODE EK19-V0
0 DZ901 6-503-032-01 DIODE DZ2J180M0L
0 DZ902 6-503-036-01 DIODE DZ2J220M0L
0 DZ903 6-503-036-01 DIODE DZ2J220M0L
0 DZ905 6-503-040-01 DIODE DZ2J300M0L
0 DZ915 6-503-022-01 DIODE DZ2J100M0L
0 DZ951 8-719-083-71 DIODE UDZSUSTE-1730B
0 DZ954 8-719-083-71 DIODE UDZSUSTE-1730B
< FUSE >
0 F945 1-576-794-11 FUSE (2A/32V)
< FUSE HOLDER >
FH901 1-533-217-41 HOLDER, FUSE
FH902 1-533-217-41 HOLDER, FUSE
< FUSIBLE RESISTOR >
0 FR929 1-246-373-11 FUSIBLE 1 10% 1/2W F
< IC >
0 IC901 6-707-742-01 IC STR-F6168-LF1352
0
IC921 6-714-671-01 IC STR-Y6763
IC923 6-711-947-01 IC MM1431CURE
IC932 6-711-947-01 IC MM1431CURE
IC941 6-712-613-01 IC SI-3010KM-TLS
< COIL >
L931 1-457-878-65 INDUCT
OR 2.2uH
L954 1-457-578-11 INDUCTOR 10uH
L956 1-457-578-11 INDUCTOR 10uH
L964 1-457-725-11 INDUCTOR 4.7uH
L967 1-457-725-11 INDUCTOR 4.7uH
< LINE FILTER >
0 LF901 1-457-054-21 COIL, LINE FILTER (TZ215: E3, E12/TZ715)
0 LF901 1-457-449-11 COIL, LINE FILTER (TZ215: E32)
0 LF902 1-457-054-21 COIL, LINE FILTER (TZ215: E3, E12/TZ715)
0 LF902 1-457-449-11 COIL, LINE FILTER (TZ215: E32)
< PHOTO COUPLER >
0 PC901 6-600-276-01 PHOTO COUPLER PS2561AL1-1-V-W
0 PC902 6-600-276-01 PHOTO COUPLER PS2561AL1-1-V-W
0 PC903 6-600-276-01 PHOTO COUPLER PS2561AL1-1-V-W
< TRANSISTOR >
0 Q901 8-729-201-53 TRANSISTOR 2SA1015-GR
0 Q922 8-729-056-46 TRANSISTOR 2SC5053T100Q
Q943 8-729-038-42 TRANSISTOR RT1N441M-TP-1
Q945 6-552-458-01 FET 2SK3577-T1B-AT
Q949 8-729-620-13 TRANSISTOR 2SC4154TP-1EF
Q950 8-729-038-42 TRANSISTOR RT1N441M-TP-1
Q969 6-551-699-01 TRANSISTOR ISA1602AM1-T111-1EF
< RESISTOR >
0 R901 1-240-938-91 METAL 1.5M 5% 0.5W F
0 R903 1-250-297-65 METAL OXIDE 100K 5% 3W F
0 R904 1-250-297-65 METAL OXIDE 100K 5% 3W F
0 R905 1-216-797-11 METAL CHIP 10 5% 1/10W
0 R906 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
0 R907 1-216-833-11 METAL CHIP 10K 5% 1/10W
0 R908 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
0 R909 1-216-833-11 METAL CHIP 10K 5% 1/10W
0 R910 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
0 R911 1-216-813-11 METAL CHIP 220 5% 1/10W
0 R912 1-216-363-00 METAL OXIDE 0.33 5% 2W F
0 R914 1-220-891-11 METAL 0.1 10% 5W F
0 R916 1-250-297-65 METAL OXIDE 100K 5% 3W F
0 R917 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
0 R919 1-216-837-11 METAL CHIP 22K 5% 1/10W
0 R922 1-250-262-41 METAL 0.39 5% 2W F
0 R923 1-218-879-11 METAL CHIP 22K 0.5% 1/10W
0 R925 1-216-797-11 METAL CHIP 10 5% 1/10W
0 R926 1-218-847-11 METAL CHIP 1K 0.5% 1/10W
R931 1-216-864-11 SHORT CHIP 0
R932 1-218-879-11 METAL CHIP 22K 0.5% 1/10W
R933 1-216-821-11 METAL CHIP 1K 5% 1/10W
R934 1-216-821-11 METAL CHIP 1K 5% 1/10W
R935 1-216-821-11 METAL CHIP 1K 5% 1/10W
R936 1-216-853-11 METAL CHIP 470K 5% 1/10W
R937 1-218-871-11 METAL CHIP 10K 0.5% 1/10W
R938 1-218-847-11 METAL CHIP 1K 0.5% 1/10W
R939 1-218-855-11 METAL CHIP 2.2K 0.5% 1/10W
R940 1-218-871-11 METAL CHIP 10K 0.5% 1/10W
R941 1-218-895-11 METAL CHIP 100K 0.5% 1/10W
R942 1-218-871-11 METAL CHIP 10K 0.5% 1/10W
R945 1-216-837-11 METAL CHIP 22K 5% 1/10W
POWER
