SECTION 4
MECHANICAL ADJUSTMENT
• TAPE MECHANISM DECK SECTION
PRECAUTION
1. Clean the following parts with a denatured-alcohol-moistened
swab:
record/playback head pinch roller
erase head rubber belts
capstan idlers
2. Demagnetize the record/playback head with a head demagne-
tizer.
3. Do not use a magnetized screwdriver for the adjustments.
4. After the adjustments, apply suitable locking compound to the
parts adjusted.
5. The adjustments should be performed with the rated power
supply voltage unless otherwise noted.
• Torque Measurement
Torque Torque Meter Meter Reading
Forward CQ-102C
36 to 61g•cm
(0.50 – 0.84 oz•inch)
Forward
CQ-102C
2 to 6g•cm
Back Tension (0.026 – 0.082 oz•inch)
Reverse CQ-102RC
36 to 61g•cm
(0.50 – 0.84 oz•inch)
Reverse
CQ-102RC
2 to 6g•cm
Back Tension (0.026 – 0.082 oz•inch)
FF, REW CQ-201B
61 to 143g•cm
(0.85 – 1.98 oz•inch)
• Tape Tension Measurement
Torque Tension Meter Meter Reading
Forward CQ-403A more than 100 g (3.52 oz)
Reverse CQ-403R more than 100 g (3.52 oz)
• CD MECHANISM DECK SECTION
To adjust the mechanism section, enter the mechanism section adjustment mode.
For how to enter the mechanism section adjustment mode, refer to each adjustment section.
DISC SENSOR ALIGMENT
1. Make sure that there is no disc in the unit.
2. Connect an oscilloscope to CN405 of the MAIN board.
3. While pressing the CLEAR and CD PLUS 1 buttons at the same time and turn ON the power.
MAIN board
CN405
D SENS
GND
HH OUT
SENS (CH1)
TEST (CH2)
GND
oscilloscope
0
=
button
)
+
button
CD PLUS 1 button
CLEAR button
CHECK button
POWER button
