HCD-RV2/RV5/RV6
5-2. FRONT PANEL SECTION
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
53
55
51
52
54
56
57
58
59
62
63
63
63
63
63
74
75
75
63
63
69
60
63
58
70
61
64
65
66
68
67
73
72
71
not supplied
not supplied
FLD701
51 4-234-015-01 KNOB RING, VOLUME
52 4-234-019-21 KNOB, VOLUME (RV5)
52 4-235-535-21 KNOB, VOLUME (RV2/RV6)
53 X-4954-789-1 DOOR (B) ASSY, CASSETTE (RV2)
53 X-4954-849-1 DOOR (B) ASSY, CASSETTE (RV5)
53 X-4954-905-1 DOOR (B) ASSY, CASSETTE (RV6)
54 X-4954-788-1 DOOR (A) ASSY, CASSETTE (RV2)
54 X-4954-848-1 DOOR (A) ASSY, CASSETTE (RV5)
54 X-4954-904-1 DOOR (A) ASSY, CASSETTE (RV6)
55 4-233-980-01 FOOT, RUBBER
56 4-238-609-71 DISPLAY (WINDOW) (RV2)
56 4-238-638-31 DISPLAY (WINDOW) (RV5/RV6)
57 4-239-346-01 SPRING (L), CASSETTE DOOR
58 4-224-104-41 DAMPER
59 1-685-098-11 MIC BOARD (RV2)
59 1-685-106-11 MIC BOARD (RV5)
59 1-685-114-11 MIC BOARD (RV6)
60 X-4954-787-1 PANEL ASSY, FRONT (RV2)
60 X-4954-847-1 PANEL ASSY, FRONT (RV5)
60 X-4954-903-1 PANEL ASSY, FRONT (RV6)
61 1-685-092-11 KEY BOARD (RV2)
61 1-685-100-11 KEY BOARD (RV5)
61 1-685-108-11 KEY BOARD (RV6)
62 4-238-629-01 HOLDER, MICROPHONE
63 4-951-620-01 SCREW (2.6X8), +BVTP
64 4-238-628-01 KNOB, MICROPHONE
65 1-685-097-11 REMOTE BOARD (RV2)
65 1-685-105-11 REMOTE BOARD (RV5)
65 1-685-113-11 REMOTE BOARD (RV6)
66 4-238-613-01 HOLDER (L), FL (RV2)
66 4-238-647-01 HOLDER (L), FL (RV5/RV6)
67 4-238-614-01 HOLDER (R), FL (RV2)
67 4-238-648-01 HOLDER (R), FL (RV5/RV6)
68 A-4676-984-A PANEL BOARD, COMPLETE (RV2)
68 A-4729-261-A PANEL BOARD, COMPLETE (RV5)
68 A-4729-403-A PANEL BOARD, COMPLETE (RV6)
69 4-243-609-01 BELT (AF)
70 1-796-485-11 MECHANISM DECK, TAPE (RV2)
70 1-796-487-11 MECHANISM DECK, TAPE (RV5/RV6)
71 4-239-347-01 SPRING (R), CASSETTE DOOR
72 4-231-841-01 SPRING (HEART CAM-B)
73 4-231-836-01 SPRING (HEART CAM-A)
74 4-243-608-01 BELT (BR)
75 4-243-610-01 BELT (AL)
FLD701 1-518-792-21 INDICATOR TUBE, FLUORESCENT (RV2)
FLD701 1-518-793-12 INDICATOR TUBE, FLUORESCENT (RV5/RV6)
