73
<MENU SETTINGS>
M03
PAGE RESUME ON
, OFF Turns the menu mode resume page display function
ON/OFF.
ALARM JUMP ON, OFF
Turns the error-related page display function ON/
OFF for when an error occurs while in menu mode.
CAMERA MENU
CTRL
OFF
, ON Displays the camera menu.
• If CAM MENU is set to ON, CCU menu operations
cannot be performed because only camera menu
operations are available.
• The camera menu is not displayed when SD signal
is output.
<DATE&TIME>
M04
DATE (YEAR) 17 to 99 Sets the date and time.
When this is changed, all logs stored on the unit will
be deleted.
DATE (MONTH) 1 to 12
DATE (DAY) 1 to 31
TIME (HOUR) 0 to 23
TIME (MINUTE) 0 to 59
TIME ZONE (HOUR) –23 to +23, 0
Sets the time zone.
TIME ZONE
(MINUTE)
0
to 59
<TALLY INPUT>
M05
R-TALLY CONTACT
RED tally input setting
This is set to CONTACT (fixed).
G-TALLY CONTACT
GREEN tally input setting
This is set to CONTACT (fixed).
Y-TALLY CONTACT
YELLOW tally input setting
This is set to CONTACT (fixed).
<ALARM SETTINGS>
M06
FORCE LEGACY OFF, ON
Set to OFF to not display the FORCE LEGACY
alarm.
CABLE OPEN OFF, ON
Set to OFF to not display the CABLE OPEN alarm.
GENLOCK ERROR OFF, ON
Set to OFF to not display the GENLOCK ERROR
alarm.
<SDI ANCILLARY DATA>
M07
VIDEO PAYLOAD ID LATEST
, 2002, 2010, 2011, 2017 Selects the standard year of the payload ID to be
added to the SDI VIDEO output.
EMBED AUDIO OFF, ON
Sets whether to embed audio in the SDI VIDEO
output.
EMBED META DATA OFF, ON
<FRONT PANEL>
M08
ASSIGNABLE
SWITCH
NONE
, BARS, CAM POWER,
FORCE LEGACY, OPTICAL
SIGNAL
Sets the function to be assigned to the assignable
button on the front panel.
NONE: No assignment.
BARS: Sets the color bar output to ON/OFF.
CAM POWER: Sets camera power to ON/OFF.
FORCE LEGACY: Forces the communication mode
to LEGACY mode.
OPTICAL SIGNAL: Turns the optical signal output
from the CCU to the camera ON/OFF.
SIGNAL BAR
DISPLAY OFF, ON
Switches the signal bar display on the front panel.
READY COLOR WHITE
, GREEN, BARS Sets the color for the ready status (during color bar
output).
BRIGHTNESS LOW, MIDDLE, HIGH
Sets the signal bar brightness level.
MAINTENANCE
Page name
Page No.
Item Set value Description
To Next Page
