23
ICD-U50/U60/U70
SECTION 6
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• CAPACITORS
uF: µF
• COILS
uH: µH
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
A-1174-560-A JACK BOARD, COMPLETE
*********************
< CAPACITOR >
C101 1-164-943-81 CERAMIC CHIP 0.01uF 10% 16V
C102 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C103 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C104 1-117-919-11 TANTAL. CHIP 10uF 20% 6.3V
C105 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C106 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C107 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C108 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C115 1-126-209-11 ELECT CHIP 100uF 20% 4V
C116 1-126-209-11 ELECT CHIP 100uF 20% 4V
C117 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C118 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C119 1-164-882-81 CERAMIC CHIP 220PF 5% 16V
C514 1-126-208-21 ELECT CHIP 47uF 20% 4V
< CONNECTOR >
CN704 1-820-201-11 CONNECTOR, BOARD TO BOARD 24P
< DIODE >
D103 8-719-074-67 DIODE EDZ-TE61-5.6B
D104 8-719-074-67 DIODE EDZ-TE61-5.6B
D105 8-719-074-67 DIODE EDZ-TE61-5.6B
D702 6-500-781-01 DIODE SML-521MUW
D710 6-501-523-01 DIODE EDZTE3.6B
< FERRITE BEAD >
FB101 1-469-084-21 FERRITE 0mH
FB102 1-469-084-21 FERRITE 0mH
FB103 1-469-084-21 FERRITE 0mH
FB104 1-469-084-21 FERRITE 0mH
< JACK >
J101 1-820-205-11 JACK, HEADPHONE (i)
< IC >
IC101 6-703-863-01 IC NJM2781RB1
< TRANSISTOR >
Q101 6-550-747-01 TRANSISTOR 3LP01S-K-TL-E
Q102 6-550-746-01 TRANSISTOR 3LN01S-K-TL-E
Q103 8-729-055-88 TRANSISTOR MCH3406-TL-E
Q104 8-729-055-88 TRANSISTOR MCH3406-TL-E
< RESISTOR >
R101 1-218-990-81 SHORT CHIP 0
R102 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R103 1-218-941-81 RES-CHIP 100 5% 1/16W
R104 1-218-981-11 RES-CHIP 220K 5% 1/16W
R105 1-218-990-81 SHORT CHIP 0
R106 1-218-977-11 RES-CHIP 100K 5% 1/16W
R108 1-218-973-81 RES-CHIP 47K 5% 1/16W
R109 1-218-957-81 RES-CHIP 2.2K 5% 1/16W
R113 1-218-929-11 RES-CHIP 10 5% 1/16W
R114 1-218-929-11 RES-CHIP 10 5% 1/16W
R115 1-218-977-11 RES-CHIP 100K 5% 1/16W
R116 1-218-977-11 RES-CHIP 100K 5% 1/16W
R119 1-218-949-11 RES-CHIP 470 5% 1/16W
R120 1-218-981-11 RES-CHIP 220K 5% 1/16W
R121 1-218-985-11 RES-CHIP 470K 5% 1/16W
R122 1-218-941-81 RES-CHIP 100 5% 1/16W
R165 1-218-990-81 SHORT CHIP 0
R166 1-218-990-81 SHORT CHIP 0
R167 1-216-864-11 SHORT CHIP 0
R168 1-216-864-11 SHORT CHIP 0
R708 1-218-949-11 RES-CHIP 470 5% 1/16W
R709 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
< SWITCH >
S706 1-572-922-11 SWITCH, SLIDE (> HOLD)
S707 1-572-922-11 SWITCH, SLIDE (DPC)
*************************************************************
A-1174-559-A MAIN BOARD, COMPLETE (U70)
A-1177-516-A MAIN BOARD, COMPLETE (U60)
A-1177-541-A MAIN BOARD, COMPLETE (U50)
*********************
1-802-099-11 DISPLAY PANEL, LIQUID CRYSTAL
2-667-089-01 HOLDER (LCD)
2-671-980-01 INSULATING SHEET (XTAL)
2-681-083-01 SHEET, BLIND
2-689-704-01 SPACER (PWB)
< CAPACITOR >
C109 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C111 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C112 1-117-919-11 TANTAL. CHIP 10uF 20% 6.3V
C113 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C114 1-128-964-91 TANTAL. CHIP 100uF 20% 6.3V
C501 1-100-661-11 TANTAL. CHIP 100uF 20% 4V
C502 1-131-862-91 TANTAL. CHIP 47uF 20% 4V
MAIN
When indicating parts by reference number,
please include the board name.
• Accessories are given in the last of this parts
list.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
•Abbreviation
CH : Chinese model.
CND : Canadian model.
JE : Tourist model.
KR : Korean model.
JACK
Ver. 1.2
