8
ICD-U50/U60/U70
1
Remove the mic unit.
2
Remove the jack.
3
dowel
4
Remove the two soldering points.
6
electret condenser
microphone (MIC901)
5
holder (mic)
7
JACK board
2-6. JACK BOARD, ELECTRET CONDENSER MICROPHONE (MIC901)
