Page #45 background imageLoading...
Page #45 background image
– 21 –
ICF-SW100E/SW100S
SECTION 2
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
NOTE:
Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
-XX and -X mean standardized parts, so they
may have some difference from the original
one.
RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
SEMICONDUCTORS
In each case, u: µ, for example:
uA... : µA... uPA... : µPA...
uPB... : µPB... uPC... : µPC...
uPD... : µPD...
CAPACITORS
uF: µF
COILS
uH: µH
When indicating parts by reference
number, please include the board.
KEY
* A-3661-960-A KEY BOARD, COMPLETE
*****************
< CONNECTOR >
CN701 1-764-370-11 HOUSING, FPC CONNECTOR (ZIF) 16P
< SWITCH >
S701 1-572-922-11 SWITCH, SLIDE (MAIN POWER)
S702 1-572-938-21 SWITCH, TACTIL (POWER ON/OFF)
S703 1-572-938-21 SWITCH, TACTIL (SLEEP)
S704 1-572-938-21 SWITCH, TACTIL (ERASE DST)
S705 1-572-938-21 SWITCH, TACTIL (ABC 1)
S706 1-572-938-21 SWITCH, TACTIL (DEF 2)
S707 1-572-938-21 SWITCH, TACTIL (GHI 3)
S708 1-572-938-21 SWITCH, TACTIL (TIME SET k +)
S709 1-572-938-21 SWITCH, TACTIL (PAGE FEED +)
S710 1-572-938-21 SWITCH, TACTIL (ENTER TIME SET)
S711 1-572-938-21 SWITCH, TACTIL (JKL 4)
S712 1-572-938-21 SWITCH, TACTIL (MNO 5)
S713 1-572-938-21 SWITCH, TACTIL (PQR 6)
S714 1-572-938-21 SWITCH, TACTIL (TIME DIFF k)
S715 1-572-938-21 SWITCH, TACTIL (PAGE FEED –)
S716 1-572-938-21 SWITCH, TACTIL (+ – *. DIRECT WORLD TIME)
S717 1-572-938-21 SWITCH, TACTIL (STU 7)
S718 1-572-938-21 SWITCH, TACTIL (VWX 8)
S719 1-572-938-21 SWITCH, TACTIL (YZ 9)
S720 1-572-938-21 SWITCH, TACTIL (TIME DIFF K)
S721 1-572-938-21 SWITCH, TACTIL (FM/AM STANDBY 1)
S722 1-572-938-21 SWITCH, TACTIL (AM BAND STANDBY 2)
S723 1-572-938-21 SWITCH, TACTIL (< >/ 0)
S724 1-572-938-21 SWITCH, TACTIL (EXE)
S725 1-572-938-21 SWITCH, TACTIL (TIME SET – K)
S726 1-572-938-21 SWITCH, TACTIL (KEY PROTECT)
S727 1-572-938-21 SWITCH, TACTIL (SYNC)
S728 1-572-938-21 SWITCH, TACTIL (SSB)
S729 1-572-938-21 SWITCH, TACTIL (LABEL EDIT)
******************************************************
*
A-3661-961-A MICROCOMPUTER BOARD, COMPLETE
********************
1-537-683-21 CONDUCTIVE BOARD, CONNECTION
3-909-845-05 PLATE, LIGHT GUIDE
3-909-849-01 CASE (LCD), SHIELD
< CAPACITOR >
BAT601 1-100-984-11 DOUBLE LAYER 0.22F 3.3V
< CAPACITOR >
C601 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C602 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C603 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C604 1-164-005-11 CERAMIC CHIP 0.47uF 25V
C605 1-164-346-11 CERAMIC CHIP 1uF 16V
C606 1-164-346-11 CERAMIC CHIP 1uF 16V
C607 1-164-346-11 CERAMIC CHIP 1uF 16V
C608 1-164-346-11 CERAMIC CHIP 1uF 16V
C609 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C610 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C611 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C612 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C613 1-164-346-11 CERAMIC CHIP 1uF 16V
C614 1-164-346-11 CERAMIC CHIP 1uF 16V
C616 1-135-254-11 TANTAL. CHIP 47uF 20% 4V
C617 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C618 1-164-346-11 CERAMIC CHIP 1uF 16V
C619 1-164-346-11 CERAMIC CHIP 1uF 16V
C620 1-164-346-11 CERAMIC CHIP 1uF 16V
C621 1-164-346-11 CERAMIC CHIP 1uF 16V
C622 1-164-346-11 CERAMIC CHIP 1uF 16V
C623 1-164-005-11 CERAMIC CHIP 0.47uF 25V
C624 1-162-961-11 CERAMIC CHIP 330PF 10% 50V
C625 1-162-961-11 CERAMIC CHIP 330PF 10% 50V
C626 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C627 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C628 1-164-346-11 CERAMIC CHIP 1uF 16V
C629 1-135-254-11 TANTAL. CHIP 47uF 20% 4V
C630 1-164-346-11 CERAMIC CHIP 1uF 16V
C631 1-162-912-11 CERAMIC CHIP 7PF 0.5PF 50V
C632 1-164-346-11 CERAMIC CHIP 1uF 16V
< CONNECTOR >
CN601 1-764-370-11 HOUSING, FPC CONNECTOR (ZIF) 16P
CN602 1-764-368-11 HOUSING, FPC CONNECTOR (ZIF) 18P
< DIODE >
D601 8-719-951-22 DIODE IMN10
MICROCOMPUTER
