Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
– 22 –
ICF-SW100E/SW100S
D602 8-719-951-22 DIODE IMN10
D603 8-719-951-22 DIODE IMN10
D604 8-719-049-21 DIODE CL-200G-C-TS (LIGHT)
D605 8-719-049-21 DIODE CL-200G-C-TS (LIGHT)
D606 8-719-941-86 DIODE DAN202U
D607 8-719-988-82 DIODE RB715F
< IC >
IC601 6-703-918-01 IC S-80823CNMC-B8IT2G
IC602 6-705-592-01 IC S-80820CNMC-B8FT2G
IC603 8-759-267-81 IC MSM64164C-031TS-K
IC604 8-759-267-82 IC MSM64164C-032TS-K
IC605 6-705-594-01 IC S-80817CNMC-B8CT2G
IC606 8-759-481-53 IC AK93C65AF-E1
IC607 6-705-460-01 IC S-812C20AUA-C2AT2G
< LIQUID CRYSTAL DISPLAY PANEL >
LCD601 1-810-427-11 DISPLAY PANEL, LIQUID CRYSTAL
< TRANSISTOR >
Q601 8-729-117-32 TRANSISTOR 2SC4177-L6
Q602 8-729-117-32 TRANSISTOR 2SC4177-L6
Q603 8-729-117-32 TRANSISTOR 2SC4177-L6
< RESISTOR >
R601 1-216-857-11 METAL CHIP 1M 5% 1/10W
R602 1-216-857-11 METAL CHIP 1M 5% 1/10W
R603 1-216-857-11 METAL CHIP 1M 5% 1/10W
R604 1-216-804-11 METAL CHIP 39 5% 1/10W
R605 1-216-804-11 METAL CHIP 39 5% 1/10W
R606 1-216-857-11 METAL CHIP 1M 5% 1/10W
R607 1-216-857-11 METAL CHIP 1M 5% 1/10W
R608 1-216-821-11 METAL CHIP 1K 5% 1/10W
R609 1-216-833-11 METAL CHIP 10K 5% 1/10W
R610 1-216-845-11 METAL CHIP 100K 5% 1/10W
R611 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R612 1-216-797-11 METAL CHIP 10 5% 1/10W
R613 1-216-797-11 METAL CHIP 10 5% 1/10W
R614 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R615 1-216-857-11 METAL CHIP 1M 5% 1/10W
R616 1-216-845-11 METAL CHIP 100K 5% 1/10W
R617 1-216-845-11 METAL CHIP 100K 5% 1/10W
R618 1-216-797-11 METAL CHIP 10 5% 1/10W
R619 1-216-797-11 METAL CHIP 10 5% 1/10W
R620 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R621 1-216-833-11 METAL CHIP 10K 5% 1/10W
R622 1-216-837-11 METAL CHIP 22K 5% 1/10W
R623 1-216-821-11 METAL CHIP 1K 5% 1/10W
R624 1-216-837-11 METAL CHIP 22K 5% 1/10W
< COMPOSITION CIRCUIT BLOCK >
RB601 1-236-631-11 RES, NETWORK
RB602 1-236-631-11 RES, NETWORK
RB603 1-236-631-11 RES, NETWORK
RB604 1-236-502-11 RES, NETWORK
RB605 1-236-502-11 RES, NETWORK
RB606 1-236-502-11 RES, NETWORK
RB607 1-236-502-11 RES, NETWORK
RB608 1-236-502-11 RES, NETWORK
RB609 1-236-875-11 RES, NETWORK
RB610 1-236-631-11 RES, NETWORK
RB611 1-236-631-11 RES, NETWORK
RB612 1-236-502-11 RES, NETWORK
RB613 1-236-502-11 RES, NETWORK
RB614 1-236-502-11 RES, NETWORK
RB615 1-236-631-11 RES, NETWORK
RB616 1-236-631-11 RES, NETWORK
RB617 1-236-631-11 RES, NETWORK
RB618 1-236-502-11 RES, NETWORK
RB619 1-236-502-11 RES, NETWORK
RB620 1-236-502-11 RES, NETWORK
RB621 1-236-502-11 RES, NETWORK
RB622 1-236-502-11 RES, NETWORK
RB623 1-236-502-11 RES, NETWORK
RB624 1-236-502-11 RES, NETWORK
RB625 1-236-502-11 RES, NETWORK
RB626 1-236-502-11 RES, NETWORK
RB627 1-236-502-11 RES, NETWORK
RB628 1-236-502-11 RES, NETWORK
RB629 1-236-631-11 RES, NETWORK
RB630 1-236-855-11 RES, NETWORK
RB631 1-236-631-11 RES, NETWORK
< SWITCH >
S601 1-572-473-11 SWITCH, TACTILE (LIGHT)
< VIBRATOR >
X601 1-760-201-11 VIBRATOR, CRYSTAL (32.768kHz)
******************************************************
* A-3679-561-A SIGNAL BOARD, COMPLETE
********************
3-831-441-99 SHEET (1)
* 3-909-850-01 CASE (DDCON), SHIELD
3-909-856-01 PLATE (BATTERY), CONTACT
* 3-909-858-01 SHIELD (VCO)
< CAPACITOR >
C1 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C2 1-162-910-11 CERAMIC CHIP 5PF 0.25PF 50V
C4 1-162-908-11 CERAMIC CHIP 3PF 0.25PF 50V
C5 1-162-910-11 CERAMIC CHIP 5PF 0.25PF 50V
C6 1-162-958-11 CERAMIC CHIP 270PF 5% 50V
C7 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C8 1-162-914-11 CERAMIC CHIP 9PF 0.5PF 50V
C9 1-162-917-11 CERAMIC CHIP 15PF 5% 50V
C10 1-162-909-11 CERAMIC CHIP 4PF 0.25PF 50V
C11 1-107-685-11 TANTAL. CHIP 15uF 20% 6.3V
C12 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C13 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C14 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C15 1-162-913-11 CERAMIC CHIP 8PF 0.5PF 50V
C16 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C17 1-107-685-11 TANTAL. CHIP 15uF 20% 6.3V
MICROCOMPUTER SIGNAL
