Sony KD-43X80K - Section 1: Kd-43 X8*K; Disassembly and Removal Caution

8
1. Remove the screws from the rear cover (4 pcs)
2. Unhook the bottom hook, starting from center.
Coin or jig to unhook bottom Rear Cover - Bezel hook
*Wrap coin in tape (55mmX25mm)
*Thickness of coin approximately 2mm
① Unhook two hooks closest to center simultaneously to prevent
lock back. (Refer to the next page for the location of hooks)
② Unhook both hooks using coin or jig.
③ Use mirror or touch the line to assist locating the hook position.
REAR COVER
1
2
3
Coin
3
<1>
<2>
SECTION 1: KD-43X8*K
TOOLS & EQUIPMENTS FFC PRECAUTIONS SECTION 1 SECTION 2 SECTION 3 SECTION 4 SECTION 5 SMART CORE APPENDIX
1-1. DISASSEMBLY AND REMOVAL CAUTION
