– 39 –
KV-PG14M40/PG14M72/L/N
KV-PG14P42/G/L/N/PG14P70
RM-952
A(1/2) BOARD VOLTAGE LIST
Ref Pin No Voltage[v]
IC001 1 4.7
20
30
40
5 5.0
6 (0) [5.0]
70
8 (0) [0.2]
9 5.0
10 5.0
11 0
12 0
13 0
14 0
15 5.0
16 0
17 0
18 0
19 0.6
20 0
21 5.0
22 0
23 (0) [5.0]
24 (5.0) [0]
25 (0) [0.3]
26 3.8
27 0
28 0.5
29 5.0
30 5.0
31 5.0
32 0
33 5.0
34 2.5
35 2.2
36 5.0
37 0
38 (2.8) [4.9]
39 0.5
40 5.0
41 5.0
42 0.1
43 0.7
44 5.0
45 (2.8) [5.0]
46 (2.8) [5.0]
47 0.4
48 0
49 0
50 0
51 0
52 0
53 5.0
54 4.8
55 5.0
56 4.8
57 5.0
58 0
59 8.8
60 (0.2) [8.8]
61 0
62 0
63 5.0
64 5.0
IC002 1 0
2 5.0
3 4.9
4 13.4
5 5.0
60
70
8 0.3
IC004 1 4.9
2 3.8
30
IC101 I 8.9
G0
O 0.4
IC201 1 0.5
2 0.5
3 0.4
4 0.4
5 0.4
6 0.4
7 0.4
8 0.4
9 0.4
10 0.4
11 0.4
12 0.4
13 0.4
14 0.4
15 0.4
16 0.4
17 0.4
18 0.4
19 0.4
20 0
21 0.4
22 0.4
23 0.4
24 0.4
25 0
26 0.4
27 0.4
28 0.3
IC203 1 0.4
2 0.4
3 15.4
40
50
6 0.4
7 7.2
8 0.5
90
10 16.5
11 8.2
12 0.3
IC301 1 0.7
2 3.7
3 0.4
4 0.4
5 (2.6) [3.6]
6 (2.9) [4.6]
7 4.8
8 4.8
9 6.7
10 0
11 3.4
12 8.1
13 (3.8) [4.4]
14 0
15 2.9
Ref Pin No Voltage[v] Ref Pin No Voltage[v]
16 0.5
17 (3.4) [3.9]
18 6.2
19 2.6
20 2.6
21 2.7
22 (2.4) [2.1]
23 3.5
24 3.5
25 3.5
26 0.1
27 2.7
28 2.7
29 2.4
30 2.4
31 2.4
32 2.4
33 0.3
34 2.5
35 2.5
36 4.7
37 8.1
38 2.5
39 4.9
40 1.1
41 (*) [0.6]
42 3.1
43 (4.0) [4.3]
44 0
45 (4.2) [4.0]
46 1.4
47 1.4
48 4.7
49 4.7
50 1.5
51 3.8
52 3.8
53 (4.6) [1.1]
54 (4.2) [8.0]
55 2.9
56 3.1
IC400 1 (0) [4.9]
2 4.4
3 8.9
4 5.2
50
6 5.2
IC402 1 1.4
2 1.3
3 2.5
40
5 2.5
6 2.5
7 5.5
8 8.9
IC551 1 0.6
2 12.9
3 12.4
4 (13) [-12.9]
5 0.3
6 12.7
7 0.6
5-4. VOLTAGE MEASUREMENT
