– 41 –
KV-PG14M40/PG14M72/L/N
KV-PG14P42/G/L/N/PG14P70
RM-952
5-5. WAVEFORMS
A BOARD WAVEFORM
568mVp-p 448mVp-p
178mVp-p
142mVp-p
17.0mVp-p 63.2mVp-p
114mVp-p
264mV23.2mVp-p
?mV
122mVp-p
180mVp-p
114mVp-p144mVp-p
200mVp-p
360mVp-p
164mVp-p
188mVp-p
900mVp-p
10mVp-p
60mVp-p
160mVp-p
PA L
PA L
1 2
PA L
NTSC3.58
2 3
NTSC3.58 PAL
3 4
NTSC3.58 PAL
4 5
PA L PA L
6 7
PAL NTSC3.58
8 8
PAL NTSC3.58
9 9
PAL NTSC3.58
10 10
PAL NTSC3.58
11 11
PA L
12
PA L
13 14
PA L
15
C BOARD VOLTAGE LIST
Ref Pin No Voltage[v]
J701 G2 (260.4) [258.4]
H2 *
KB 120
KG (120) [125]
KR (117) [119]
Q705 B 8.9
C (8.3) [124.4]
E (8.3) [0.3]
Q710 B 2.7
C 8.3
E 2.0
Q711 B 2.7
C 8.3
E 2.0
Q704 B 8.9
C (121.7) [123.2]
E (8.3) [6.3]
Q706 B 8.9
C 119
E (8.3) [6]
Q707 B (122) [125.2]
C 7.3
E (120) [125.2]
Q708 B (120.7) [123.4]
C 7.4
E (118.2) [124.3]
Q709 B (119) [120.1]
C (7.3) [8]
E (116) [119.8]
Q712 B (2.7) [0.3]
C (8.3) [6]
E (2.1) [1.8]
