– 47 –
KV-PG14M40/PG14M72/L/N
KV-PG14P42/G/L/N/PG14P70
RM-952
SECTION 6
EXPLODED VIEWS
• Items marked " ∗ " are not stocked since
they are seldom required for routine
service. Some delay should be
anticipated when ordering these items.
The components identified by
shading and mark ! are critical
for safety.
Replace only with part number
specified.
NOTE:
• Items with no part number and no
description are not stocked because
they are seldom required for routine
service.
• The construction parts of an assembled
part are indicated with a collation
number in the remark column.
6-1. PICTURE TUBE AND CHASSIS
r
: 7-685-648-79 SCREW +BVTP 3 × 12
p : 7-685-663-71 SCREW +BVTP 4 × 16
Caution : Do not take out CRT Support block while TV set in standing position.
4
13
7
8
8
9
10
12
14
15
25
5
17
13
6
16
18
20
21
23
22
19
11
1
2
27
26
24
3
16
28
To Next Page
