KV-PG14M40/PG14M72/L/N
KV-PG14P42/G/L/N/PG14P70
RM-952
REF NO. PART NO. DESCRIPTION REMARK REF NO. PART NO. DESCRIPTION REMARK
– 49 –
* A-1299-645-A A BOARD COMPLETE (KV-PG14M40)
* A-1299-637-A A BOARD COMPLETE
(KV-PG14M72/PG14M72/L/PG14M72/N)
* A-1299-632-A A BOARD COMPLETE (KV-PG14P42/
PG14P42/G/PG14P42/L/PG14P42/N)
* A-1299-614-A A BOARD COMPLETE (KV-PG14P70)
********************
1-682-199-21 PWB, A
* 4-055-304-01 HOLDER, LED
* 4-082-454-01 HOLDER, FBT
* 4-352-844-01 PIN, LEAD, COATING
4-382-854-01 SCREW (M3X8), P, SW (+)
4-382-854-21 SCREW (M3X14), P, SW (+)
7-685-648-79 SCREW +BVTP 3X12 TYPE2 IT-3
<CAPACITOR>
C001 1-162-962-11 CERAMIC CHIP 470PF 10.00% 50V
C002 1-162-962-11 CERAMIC CHIP 470PF 10.00% 50V
C004 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
C005 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
C006 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
C007 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
C009 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
C010 1-162-927-11 CERAMIC CHIP 100PF 5.00% 50V
C011 1-162-927-11 CERAMIC CHIP 100PF 5.00% 50V
C012 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
C013 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
C014 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
C015 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
C016 1-162-927-11 CERAMIC CHIP 100PF 5.00% 50V
C017 1-126-947-11 ELECT 47UF 20.00% 16V
C018 1-126-961-11 ELECT 2.2UF 20.00% 50V
C019 1-162-962-11 CERAMIC CHIP 470PF 10.00% 50V
C020 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
C021 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
C022 1-162-927-11 CERAMIC CHIP 100PF 5.00% 50V
C023 1-162-927-11 CERAMIC CHIP 100PF 5.00% 50V
C024 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
C025 1-135-834-91 CERAMIC CHIP 2.2E+06PF 6.3V
C026 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
C027 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
C028 1-162-927-11 CERAMIC CHIP 100PF 5.00% 50V
C029 1-162-927-11 CERAMIC CHIP 100PF 5.00% 50V
C030 1-162-927-11 CERAMIC CHIP 100PF 5.00% 50V
C031 1-162-927-11 CERAMIC CHIP 100PF 5.00% 50V
C032 1-162-965-11 CERAMIC CHIP 0.0015UF 10.00% 50V
C033 1-162-927-11 CERAMIC CHIP 100PF 5.00% 50V
C034 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
C035 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
C036 1-163-038-91 CERAMIC CHIP 0.1UF 25V
(KV-PG14M40/PG14P70/PG14M72/L/N)
C036 1-164-360-11 CERAMIC CHIP 0.1UF 16V
(KV-PG14P42/G/L/N)
C037 1-162-927-11 CERAMIC CHIP 100PF 5.00% 50V
C038 1-162-927-11 CERAMIC CHIP 100PF 5.00% 50V
C039 1-163-038-91 CERAMIC CHIP 0.1UF 25V
(KV-PG14M40/PG14P70/PG14M72/L/N)
C039 1-164-360-11 CERAMIC CHIP 0.1UF 16V
(KV-PG14P42/G/L/N)
C041 1-162-924-11 CERAMIC CHIP 56PF 5.00% 50V
C042 1-162-927-11 CERAMIC CHIP 100PF 5.00% 50V
C043 1-162-927-11 CERAMIC CHIP 100PF 5.00% 50V
C044 1-162-924-11 CERAMIC CHIP 56PF 5.00% 50V
C045 1-126-962-11 ELECT 3.3UF 20.00% 50V
C046 1-162-995-11 CERAMIC CHIP 0.022UF 50V
C047 1-113-619-11 CERAMIC CHIP 0.47UF 10V
C048 1-126-965-91 ELECT 22UF 20.00% 50V
C049 1-163-038-91 CERAMIC CHIP 0.1UF 25V
(KV-PG14M40/PG14P70/PG14M72/L/N)
C049 1-164-360-11 CERAMIC CHIP 0.1UF 16V
(KV-PG14P42/G/L/N)
C050 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
C051 1-163-038-91 CERAMIC CHIP 0.1UF 25V
(KV-PG14M40/PG14P70/PG14M72/L/N)
C051 1-164-360-11 CERAMIC CHIP 0.1UF 16V
(KV-PG14P42/G/L/N)
C052 1-126-935-11 ELECT 470UF 20.00% 10V
C053 1-126-935-11 ELECT 470UF 20.00% 10V
C054 1-104-666-11 ELECT 220UF 20.00% 25V
C055 1-162-960-11 CERAMIC CHIP 220PF 10.00% 50V
C056 1-162-927-11 CERAMIC CHIP 100PF 5.00% 50V
C057 1-162-960-11 CERAMIC CHIP 220PF 10.00% 50V
C058 1-162-960-11 CERAMIC CHIP 220PF 10.00% 50V
C061 1-162-966-11 CERAMIC CHIP 0.0022UF 10.00% 50V
C063 1-162-923-11 CERAMIC CHIP 47PF 5.00% 50V
C100 1-162-964-11 CERAMIC CHIP 0.001UF 10.00% 50V
C101 1-126-964-11 ELECT 10UF 20.00% 50V
C102 1-163-038-91 CERAMIC CHIP 0.1UF 25V
(KV-PG14M40/PG14P70/PG14M72/L/N)
C102 1-164-360-11 CERAMIC CHIP 0.1UF 16V
(KV-PG14P42/G/L/N)
C103 1-163-038-91 CERAMIC CHIP 0.1UF 25V
(KV-PG14M40/PG14P70/PG14M72/L/N)
C103 1-164-360-11 CERAMIC CHIP 0.1UF 16V
(KV-PG14P42/G/L/N)
C104 1-163-038-91 CERAMIC CHIP 0.1UF 25V
(KV-PG14M40/PG14P70/PG14M72/L/N)
C104 1-164-360-11 CERAMIC CHIP 0.1UF 16V
(KV-PG14P42/G/L/N)
C105 1-163-038-91 CERAMIC CHIP 0.1UF 25V
(KV-PG14M40/PG14P70/PG14M72/L/N)
SECTION 7
ELECTRICAL PARTS LIST
NOTE:
The components identified by shading
and mark ! are critical for safety.
Replace only with part number specified.
When indicating parts by reference
number, please include the board name.
• Items marked " ∗ " are not stocked since
they are seldom required for routine
service. Some delay should be antici-
pated when ordering these items.
• All variable and adjustable resistors have
characteristic curve B, unless otherwise
noted.
• All resistors are in ohms
• F : nonflammable
CAPACITORS
• MF : µF, PF : µµF
COILS
• MMH : mH, UH : µH
A
