Sony MEX-N6000BH Service Manual

MEX-GS810BH/N6000BH
22
3-7. ANTENNA BT (BT1) (GS810BH)
3-8. ANTENNA BT (BT1) (N6000BH)
:LUHVHWWLQJ
connector connector
lead wire with connector
lead wire with connector
4 screw (T)
5 antenna BT
(BT1)
3 lead wire with connector
(CN1002)
OK
NG
2 connector
(CN1300)
1
Remove the cable
from lead pin.
lead wire from antenna BT
antenna BT
lead pin
front side
MAIN
board
connector
(CN1002)
connector
(CN1300)
Note:
Connection cable
(automobile) do not
ride on connector.
:LUHVHWWLQJ
connector connector
lead wire with connector
lead wire with connector
3 screw (T)
4 antenna BT
(BT1)
2 lead wire with connector
(CN1002)
OK
NG
antenna BT
front side
MAIN board
1 filament
tape
filament
tape
connector
(CN1002)
lead wire from antenna BT
