Sony MHC-V5 Service Manual

MHC-V5
MHC-V5
6464
• Waveforms
– ARAGON Board –
8
IC101 wf (SSI3_BCKO)
1 V/DIV, 200 ns/DIV
324 ns
4.5 Vp-p
7
IC101 qf (AUDIO_CLK_OUT)
1 V/DIV, 50 ns/DIV
81 ns
4.1 Vp-p
20.8 Ps
3.4 Vp-p
9
IC101 wh (SSI3_LRCKO)
1 V/DIV, 10 Ps/DIV
0
IC101 wl (SSI0_BCKO)
1 V/DIV, 200 ns/DIV
324 ns
4.5 Vp-p
20.8 Ps
3.6 Vp-p
qa
IC101 e; (SSI0_LRCKO)
1 V/DIV, 10 Ps/DIV
qs
IC101 yk (RTC-X2)
500 mV/DIV, 20 Ps/DIV
30.4 Ps
1.7 Vp-p
qd
IC101 ua (XTAL)
1 V/DIV, 50 ns/DIV
75 ns
3.3 Vp-p
qf
IC101 os (AUDIO-X2)
1 V/DIV, 50 ns/DIV
81.5 ns
3.5 Vp-p
qg
IC001 2 (VBST1)
5 V/DIV, 500 ns/DIV
18.4 Vp-p
qh
IC001 qg (VBST2)
5 V/DIV, 2 Ps/DIV
6.4 Ps
18.4 Vp-p
qj
IC002 2 (VBST1)
5 V/DIV, 2 Ps/DIV
5.8 Ps
19.8 Vp-p
qk
IC002 qg (VBST2)
5 V/DIV, 2 Ps/DIV
5.8 Ps
18.4 Vp-p
6
IC451 8 (X2)
1 V/DIV, 50 ns/DIV
83 ns
2.9 Vp-p
1
IC301 8 (XTALO)
500 mV/DIV, 20 ns/DIV
37.2 ns
1.2 Vp-p
59 ns
4.5 Vp-p
2
IC301 <zzx (ACLK)
1 V/DIV, 50 ns/DIV
3
IC301 <zzc (ABCK)
1 V/DIV, 200 ns/DIV
352 ns
4.5 Vp-p
22.7 Ps
4 Vp-p
4
IC301 <zzm (ALRCK)
1 V/DIV, 10 Ps/DIV
5
IC301 <zxc (RFIP)
(CD play mode)
200 mV/DIV, 100 ns/DIV
1 Vp-p
– D-AMP Board –
7.4 Ps
13.4 Vp-p
e;
Q2004 (BASE)
5 V/DIV, 5 Ps/DIV
w;
IC1003 7
500 mV/DIV, 2 Ps/DIV
2 Ps
1.6 Vp-p
– FL Board –
• IC Block Diagrams
– ARAGON Board –
IC103 BU4229F-TR
–
+
VDD
2
GND
1
VOUT
4
CT
3
VREF
IC303 MM1701CHBE
1VOUT
2NC
3GND
4CN
5CONT
7NC
6NC
8VIN
CURRENT
LIMITTER
DRIVER
BIAS
REFERENCE
THERMAL
SHUTDOWN

Sony MHC-V5 Specifications

General

On/off switch	Yes
Product color	Black
Recommended usage	Universal
Suitable for outdoor use	-
Speaker type	3-way
Driver diameter	250 mm
Speaker position	Front
Tweeter diameter	40 mm
Number of drivers	3
Speaker placement	Floor
Audio output channels	1.0 channels
Mid-range driver diameter	100 mm
Number of tweeter drivers	1
Recommended amplifier power (max)	240 W
Recommended amplifier power (min)	0.5 W
Impedance	5 Ω
Frequency range	- Hz
RMS rated power	1440 W
Peak Music Power Output (PMPO)	15840 W
Number of amplifier channels	2 channels
Power source type	AC
USB 2.0 ports quantity	2
Connectivity technology	Wired & Wireless
AC input voltage	120 V
AC input frequency	60 Hz
Type	Home audio mini system

Weight and Dimensions

Depth	325 mm
Width	339 mm
Height	908 mm
Weight	18000 g
