6-8. FRONT PANEL SECTION
• Rear view
351 4-474-156-11 CUSHION (E 0.5) (US)
352 4-535-349-01 SHEET, FL
353 3-831-441-11 CUSHION, SPEAKER GRILLE (FAB-NW)
(See Note)
354 4-986-971-12 SCREW (3.5)
355 3-087-053-01 +BVTP2.6 (3CR)
356 4-474-153-01 CUSHION (H)
357 4-475-030-01 ADHESIVE SHEET (NFC)
358 X-2588-867-1 PANEL, FRONT ASSY (E2, E51)
358 X-2588-880-1 PANEL, FRONT ASSY (US)
359 4-474-153-11 CUSHION (H)
360 4-474-156-61 CUSHION (E 0.5)
361 A-1988-838-A USB BOARD, COMPLETE (E2, E51)
361 A-2044-711-A USB BOARD, COMPLETE (US)
BT1 1-492-699-11 BLUETOOTH MODULE
FC3 1-457-369-12 CORE, FERRITE (US)
FC4 1-500-635-11 CORE, FERRITE
FFC5 1-828-004-51 WIRE (FLAT TYPE) (23 CORE)
FFC6 1-828-691-61 WIRE (FLAT TYPE) (8 CORE)
FFC7 1-828-700-61 WIRE (FLAT TYPE) (10 CORE)
FFC9 1-828-343-11 WIRE (FLAT TYPE) (15 CORE)
NFC1 8-989-470-00 RC-S801/A (NFC module)
SP2 1-858-981-11 LOUDSPEAKER (4 cm) (Tweeter) (L-CH)
SP4 1-858-981-11 LOUDSPEAKER (4 cm) (Tweeter) (R-CH)
#2 7-685-646-71 SCREW +BVTP 3X8 TYPE2 IT-3
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
