Sony NSX-40GT1 User Manual

Return to Top
Keyboard area
Return to Top
Side area
(PAUSE)
Pauses or re-starts playback.
(7)
(SEARCH)
Displays the Quick Search Box.
Type your query in the Quick Search Box, and the Internet TV will suggest content from
various media providers.
(1)
Fn
Holding Fn down and pressing a key with purple characters is a shortcut to the labeled
function.
Note
(2)
Fn + CH +/−: Moves page up or down.
Fn + GUIDE: Displays the BD's or DVD's Top Menu.
Fn + DVR: Displays the BD-ROM's Pop-up Menu.
Fn + 1: Displays the Settings application.
Fn + 2: Switches the language track.
Fn + 3: Turns closed captions on or off.
Fn + 4: Displays the disc info.
Shortcut keys are not available depending on the launching application.
(DELETE)
Deletes input characters.
(3)
NSX-24GT1/NSX-32GT1/NSX-40GT1/NSX-46GT1
21

Sony NSX-40GT1 Specifications

Power

power requirements voltage	AC 120V
power requirements frequency	60Hz
power consumption in operation	122 W
power consumption in standby	0.5 W
power consumption in download acquisition mode	34 Wh/day

Display

aspect ratio	16:9
backlight type	Edge LED
display device	LCD
display resolution	1920 x 1080p (Full HD)
screen size	40 inches
viewing angle right/left	178(89/89)
viewing angle up/down	178(89/89)

Audio

audio power output	20W (10W x 2)
audio dac	48kHz/24bit
speakers total	2

Inputs and Outputs

ac power	1 (Rear)
composite video input	1 (Rear)
component video input	1 (Rear)
hdmi connections input	4 (2 Rear/ 2 Side)
analog audio input	1 (Rear)
analog audio output	1 (Headphone)
digital audio optical output	1 (Rear)
usb 2.0	4 (Side)
ethernet connections	10BASE-T/100BASE-TX/1000BASE-T (Rear)

Weight and Dimensions

dimensions without pedestal	37 5/8 x 23 1/8 x 2 1/8 inches
dimensions with pedestal	37 5/8 x 24 3/8 x 11 3/4 inches
packaging dimensions	41 1/8 x 27 x 6 3/4 inches
weight without pedestal	37.7 lbs
weight with pedestal	41.5 lbs
