(or Enter) to select or confirm the highlighted item.
Operations on a web browser
To move the pointer, slide your thumb on the OFS (Optical Finger Sensor).
To click, press down the OFS.
Shortcut operations
Holding Fn down and pressing a key with purple characters is a shortcut to the labeled function.
For details, see Keys and Buttons.
Tips
To return to the previous screen on the Internet TV, press (BACK). With some applications,
you may not be able to use
(BACK) to return to the previous screen. In such case, hold
down
(HOME) to display the Recent apps list then select another application.
To return to the previous screen on the currently displayed device, press ESC.
For more information on the location of keys or buttons, see Keys and Buttons.
When the Keypad does not work
When the Keypad does not work correctly, follow the procedures below. First, confirm the
batteries are inserted properly.
Press CONNECT on the Internet TV for more than two seconds to display the pairing screen.1.
Hold down Fn and Enter until the pairing screen disappears.
The AMP indicator blinks fast twice when pairing starts, and blinks slowly twice when pairing
2.
NSX-24GT1/NSX-32GT1/NSX-40GT1/NSX-46GT1
7

Other manuals for Sony NSX-40GT1

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Sony NSX-40GT1 and is the answer not in the manual?

Sony NSX-40GT1 Specifications

Power IconPower
power requirements voltageAC 120V
power requirements frequency60Hz
power consumption in operation122 W
power consumption in standby0.5 W
power consumption in download acquisition mode34 Wh/day
Display IconDisplay
aspect ratio16:9
backlight typeEdge LED
display deviceLCD
display resolution1920 x 1080p (Full HD)
screen size40 inches
viewing angle right/left178(89/89)
viewing angle up/down178(89/89)
Audio IconAudio
audio power output20W (10W x 2)
audio dac48kHz/24bit
speakers total2
Inputs and Outputs IconInputs and Outputs
ac power1 (Rear)
composite video input1 (Rear)
component video input1 (Rear)
hdmi connections input4 (2 Rear/ 2 Side)
analog audio input1 (Rear)
analog audio output1 (Headphone)
digital audio optical output1 (Rear)
usb 2.04 (Side)
ethernet connections10BASE-T/100BASE-TX/1000BASE-T (Rear)
Weight and Dimensions IconWeight and Dimensions
dimensions without pedestal37 5/8 x 23 1/8 x 2 1/8 inches
dimensions with pedestal37 5/8 x 24 3/8 x 11 3/4 inches
packaging dimensions41 1/8 x 27 x 6 3/4 inches
weight without pedestal37.7 lbs
weight with pedestal41.5 lbs
