1-4-3. BU Check Flow [zz] ~
Before
BU Replacement ~
1-4-4. BU (Optical Block) Repair Guide
BDP 7G (BDP-BX39/S390)
s
e
ries component structure is as same as conventional DVD Players.
However BD player requires precise read out functions and also secure contents Protection
system.
Since above requirement, it is necessary to set/adjust BU data to EEPROM.
The following cases need Adjustments;
(1)Replace BU (MB is original)
(2)Replace MB (BU is original)
(3)Replace both BU and MB
•JIG Requirement
Digital camera (recommend with macro mode)
Barcode decoder (BDPRdec_ver3.0
) installed in JIG PC’s
USB memory
ESD work bench
•Procedure (all cases)
Refer the diagram
Remarks:
The servo adjustment procedure will be carried out during OP data Writing.
There is no manual adjustment procedure. LD ON TIME history doesn’t carry over.
Do not touch any optical block parts, Turn Table and during replacing. BD Laser diode
is very sensitive!
Optical Block Unit (BU) IOP check flow (zz) ~ [Before BU Replacement]
Enter Service Mode
Press
<OPEN/CLOSE>., <PLAY>,<STOP>
and plug in AC Power
Inside *Service Mode Menu
Select [8] Drive
Inside *Drive
Select [7] OP Check Menu
Inside *OP Check Menu
Select [2] dIOP then press 'ENTER'
Specification dIOP
BD: 6mA
DVD, CD: 9mA
IOP out of specification need BU
replacement
Optical Block Unit (BU) replace
(Flowchart yy)
AC Power OFF
NO
YES
+
-
+
-
BDP-BX39/S390
To Next Page
