Sony RMT-B119P - IC Pin Function Description

Pin Symbol Type Description
K9 DVCC12_K Power 1.2V digital power
K11 DVCC12_K Power 1.2V digital power
K12 DVCC12_K Power 1.2V digital power
K15 DVCC12_K Power 1.2V digital power
K17 DVCC12_K Power 1.2V digital power
K18 DVCC12_K Power 1.2V digital power
L9 DVCC12_K Power 1.2V digital power
L17 DVCC12_K Power 1.2V digital power
L18 DVCC12_K Power 1.2V digital power
N17 DVCC12_K Power 1.2V digital power
N18 DVCC12_K Power 1.2V digital power
P9 DVCC12_K Power 1.2V digital power
P18 DVCC12_K Power 1.2V digital power
R17 DVCC12_K Power 1.2V digital power
T9 DVCC12_K Power 1.2V digital power
T11 DVCC12_K Power 1.2V digital power
T12 DVCC12_K Power 1.2V digital power
T14 DVCC12_K Power 1.2V digital power
T16 DVCC12_K Power 1.2V digital power
T17 DVCC12_K Power 1.2V digital power
U9 DVCC12_K Power 1.2V digital power
U11 DVCC12_K Power 1.2V digital power
U12 DVCC12_K Power 1.2V digital power
U14 DVCC12_K Power 1.2V digital power
U15 DVCC12_K Power 1.2V digital power
U16 DVCC12_K Power 1.2V digital power
H14 DGND12_K Ground Digital ground
H21 DGND12_K Ground Digital ground
J22 DGND12_K Ground Digital ground
K21 DGND12_K Ground Digital ground
L5 DGND12_K Ground Digital ground
L6 DGND12_K Ground Digital ground
L7 DGND12_K Ground Digital ground
L10 DGND12_K Ground Digital ground
L11 DGND12_K Ground Digital ground
L12 DGND12_K Ground Digital ground
L13 DGND12_K Ground Digital ground
L14 DGND12_K Ground Digital ground
L15 DGND12_K Ground Digital ground
L16 DGND12_K Ground Digital ground
L21 DGND12_K Ground Digital ground
M10 DGND12_K Ground Digital ground
M12 DGND12_K Ground Digital ground
M14 DGND12_K Ground Digital ground
M16 DGND12_K Ground Digital ground
N4 DGND12_K Ground Digital ground
N10 DGND12_K Ground Digital ground
N11 DGND12_K Ground Digital ground
N13 DGND12_K Ground Digital ground
N15 DGND12_K Ground Digital ground
N16 DGND12_K Ground Digital ground
N22 DGND12_K Ground Digital ground
N23 DGND12_K Ground Digital ground
P10 DGND12_K Ground Digital ground
P12 DGND12_K Ground Digital ground
P14 DGND12_K Ground Digital ground
P1
6 DGND12_K Ground Digital ground
R4 DGND12_K Ground Digital ground
R10 DGND12_K Ground Digital ground
R11 DGND12_K Ground Digital ground
R12 DGND12_K Ground Digital ground
R13 DGND12_K Ground Digital ground
R14 DGND12_K Ground Digital ground
R15 DGND12_K Ground Digital ground
T21 DGND12_K Ground Digital ground
U6 DGND12_K Ground Digital ground
U22 DGND12_K Ground Digital ground
V5 DGND12_K Ground Digital ground
Y13 DGND12_K Ground Digital ground
Y15 DGND12_K Ground Digital ground
Y17 DGND12_K Ground Digital ground
Y19 DGND12_K Ground Digital ground
A
A19 DGND12_K Ground Digital ground
MAIN SYSTEM CONTROL PIN FUNCTION (MB-144 BOARD IC 101 : CXD90007G-AB)
BDP-BX39/S390
IC PIN FUNCTION DESCRIPTION
SECTION 6
6-1
