30
HCD-C700/C900
SECTION 5
DIAGRAMS
• CIRCUIT BOARDS LOCATION
LOAD MOTOR boar
d
POWER board
RF-240 board
INIT/COUNT SW board
SENSOR board
SENSOR 2 board
OUT SW board
CONNECTOR
board
IN SW board
COMPONENT board
CLAMP MOTOR
board
DVD board
Tuner UNIT
I/O board
AMP board
DDCON-1089 board
FP-1089 board
DS-1089 board
SW-1089 board
FU-1089 board
HP-1089 board
PW-1089 board
