SECTION 2
GENERAL
This section is extracted from
instruction manual.
LOCATION OF CONTROLS
– Front Panel –
– Rear Panel –
1 I/u (POWER) button
2 REMOTE CONTROL receiver
3 ONCE, DAILY, REC, SLEEP indicator
4 REC button
5 DAILY button
6 ONCE button
7 CLOCK/TIMER SET button
8 STEREO/MONO button
9 SLEEP button
!º MULTI CONTROLLER knob
!¡ ENTER/YES button
!™ MENU/NO button
!£ BAND button
!¢ RESET button
!∞ Fluorescent indicator tube
!§ AUTO/n button
!¶ MANUAL/N button
!• DISPLAY button
!ª TUNER OUT terminal
@º FM/AM ANTENNA terminal
@¡ AU BUS terminal
@™ SYSTEM CONTROL terminal
@£ AC OUTLET (for TA-MS717)
@¢ POWER cord
